M510 Linear Type Automatic Tool Changer

Application:

wood door, wooden picture frame, plank plate, solid wave plate processing, screen and window processing, cabinet gate, building model, wood pattern, aero wood pattern, propeller, foam vehicle mould, the tri-dimensional surface of violin, and other musical instruments, external cutting and engrave pattern, handwriting of frame on the instruments.

Features:

1.Gantry movement

2.Heavy grid steel welded structure

3.X ,Y axis rack and pinion drive, Z axis precision ball screw drive

4.8-position straight line tool holder system

5.Automatic tool change.

6.24,000rpm high-performance Italian HSD spindle

7.Automatic tool length compensation system

8.PC-based CNC control system

9.High torque/high speed servo motor(brushless AC closed loop servo)

10.Powerful regenerative vacuum pump and the gridded suction table

11.Pneumatic stabilizer to ensure a balanced operation of Z-axis

12.Three-axis rectangular linear guide rail 25mm wide

13.Independently controllable suction table area for different work-piece

Technical performance:

Space-Overall     2250*3800*1900mm

Max working size  1500*3000*200mm

Frame: Heavy grid Steel welded structure

Table Type : Vacuum suction table with 5.5kw

Spindle: Italy 5.5kw HSD

Control System: NC6A control software

Rail way: Taiwan Hiwin 25mm rectangle guide rail

Drive Type: Taiwan Delta Servo Motor with 750w

Drives: X.Y axis rack and pinion, Z axis precision Ball screw

Tool style: Liner Magazine,8tools,Tool change can be accomplished automatically.

Tool holder diameter:3.175-18mm

Tool change time:10s

Speed:24000rpm

Travel speed:40000mm/min

Cutting speed:20000mm/min

Voltage:3 Phase 380V 60HZ

Weight :1600kg
