CAST STEEL OR STAINLESS STEEL STEAM TRAP INVERTED BUCKET DESIGN
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | ciphy | Place of Origin | China | |
| Model Number | STDXTH-880T |
Product Description
DESIGN DESCRIPTION:
INTEGRAL STRAINER.
FREE-FLOATING STAINLESS MECHANISM
AUTO-DISCHARGE ORIFICE AT THE TOP OF TRAP.
WITH CONTINUOUS AIR VENTING AT STEAM TEMPERATURE,
CONTINUING OR INTERRUPT DRAIN CHARACTERISTIC,
DESIGN:FACTORY STANDARDS.
FLUID APPLICATION: VAPOR, CONDENSATION.
MEDIA MINIMUM TEMPERATURE: 25°C
END THREAD: NPT OR OTHER.
SIZE: DN10-DN30
MAXIMUM ALLOWABLE WORKING PRESSURE AND TEMPERATURE:
PRESSURE RATING : PN16 PN25
MAX WORKING PRSSURE : 1.6MPa 2.5MPa
MAX WORKING TEMPERATURE: 2500C 3500C
TEST PRESSURE:
SHELL (WATER) : 2.4MPA 1.6MPA
WORKING STATION (STEM) : 3.75MPA 1.6MPA
PARTS AND MATERIAL :
1 TOP NUT :CARBON STEEL
2 SEAT :STAINLESS STEEL
3 GASKET: GRAPHITE
4 DISC :STAINLESS STEEL
5 LEVER :STAINLESS STEEL
6 FLOAT BUCKET :STAINLESS STEEL
7 BOTTOM NUT: CARBON STEEL
8 SCREEN: STAINLESS STEEL
9 SPRING RING: CARBON STEEL
10 BODY :CATBON STEEL
OTHER MATERIALS ARE AVAILABLE UPON REQUEST.
DESIGN DESCRIPTION:
INTEGRAL STRAINER.
FREE-FLOATING STAINLESS MECHANISM
AUTO-DISCHARGE ORIFICE AT THE TOP OF TRAP.
WITH CONTINUOUS AIR VENTING AT STEAM TEMPERATURE,
CONTINUING OR INTERRUPT DRAIN CHARACTERISTIC,
DESIGN:FACTORY STANDARDS.
FLUID APPLICATION: VAPOR, CONDENSATION.
MEDIA MINIMUM TEMPERATURE: 25°C
END THREAD: NPT OR OTHER.
SIZE: DN10-DN30
MAXIMUM ALLOWABLE WORKING PRESSURE AND TEMPERATURE:
PRESSURE RATING : PN16 PN25
MAX WORKING PRSSURE : 1.6MPa 2.5MPa
MAX WORKING TEMPERATURE: 2500C 3500C
TEST PRESSURE:
SHELL (WATER) : 2.4MPA 1.6MPA
WORKING STATION (STEM) : 3.75MPA 1.6MPA
PARTS AND MATERIAL :
1 TOP NUT :CARBON STEEL
2 SEAT :STAINLESS STEEL
3 GASKET: GRAPHITE
4 DISC :STAINLESS STEEL
5 LEVER :STAINLESS STEEL
6 FLOAT BUCKET :STAINLESS STEEL
7 BOTTOM NUT: CARBON STEEL
8 SCREEN: STAINLESS STEEL
9 SPRING RING: CARBON STEEL
10 BODY :CATBON STEEL
OTHER MATERIALS ARE AVAILABLE UPON REQUEST.
