PC Solid Embossed Sheet

Specifications

 PC solid embossed sheet

Gensin polycarbonate embossed sheet has high impact strength, can provide drip-drop pattern, barleycorn pattern, diamond pattern and litchi pattern.

Specifications:
1. Thickness: 2.2 to 16mm
2. Maximum width: 2,100mm
3. Length: any dimension
4. Specific gravity: 1.2g/cm3

5. Colors: clear, blue, green, opal, brown,bronze,etc.

6. Pattern: drip-drop pattern, barleycorn pattern, diamond pattern and litchi pattern.

Technical features:
1. Impact strength: 850J/m ,the impact strength of solid PC sheets is 250 times
that of glass, 20-30 times of PMMA sheet
2. Light transmission: 80%-90% for different thickness of clear color

3. UV resistance:with our 50μm thickness UV layer ,the sheet can filter 99% ultraviolet radiation in sunlight
4. Specific gravity: 1.2 g/cm
5. Coefficient of thermal expansion: 0.065 mm/m^oC

6. Temperature: -40^oC to 120^oC

7. Heat conductivity: 2.3-3.9 W/m^{2   oC}
8. Tensile strength: >60N/mm²
9. Flexural strength: 100N/mm²
10.Modulus of elasticity: 2,400mPa
11.Tensile street at break: >65mPa
12.Elongation at break: >100%
13.Specific heat: 1.16J/kg^k
14.Heat deflection temperature: 140^oC
15.Soundproof index:4mm thickness--27dB,5mm--28dB,6mm--29dB,8mm--31dB,10mm-32dB

                          12mm--34dB

Applications:

1.Bathroom

2.Upholster, Lighting

3.Indoor partion, Folding screen

4.Ceiling, Sunshades
