Polycarbonate Embossed Sheet

FOB Price

Negotiable / Ton

2 Tons(Min. Order)

Port Shanghai
Payment TermsT/T D/P D/A

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China		Brand Name	Lixan/Liyans
Model Number	GA-201

Product Description

Specifications

polycarbonate embossed sheets,
duced by 100% virgin Sabic(GE) material
2. one side UV blocking layer
3.10-year warrant

PC embossed sheets

Specifications:
Thickness: 2-12mm
Maximum width: 2,100mm
Length: any dimension
Specific gravity: 1200kg/cbm
Colors: clear, blue, green, opal, brown,bronze,etc.

Technical features:
Impact strength: 850J/m ,the impact strength of solid PC sheets is 250 times
that of glass, 20-30 times of PMMA sheet
Light transmission: 80%-90% for different thickness of clear color

UV resistance:with our 50μm thickness UV layer ,the sheet can filter 99% ultraviolet radiation in sunlight
Specific gravity: 1200kg/cbm
Coefficient of thermal expansion: 0.065 mm/m^oC

Temperature: -40^oC to 120^oC

Heat conductivity: 2.3-3.9 W/m^{2 oC}
Tensile strength: >60N/mm²
Flexural strength: 100N/mm²
Modulus of elasticity: 2,400mPa
Tensile street at break: >65mPa
Elongation at break: >100%
Specific heat: 1.16J/kg^k
Heat deflection temperature: 140^oC
Soundproof index:4mm thickness--27dB,5mm--28dB,6mm--29dB,8mm--31dB,10mm-32dB

12mm--34dB
