Home > Products > Stainless steel wire drawing machine > stainless steel wire drawing machine
stainless steel wire drawing machine
- Shanghai or Suzhou
- T/T
You May Like
Product Details
| Condition | New | CNC or Not | Normal | |
| Place of Origin | Jiangsu, China | Brand Name | Wanyi | |
| Model Number | LZ600 straight line | Voltage | 220 and 380V | |
| Power(W) | 11KW each | Dimension(L*W*H) | Optional | |
| Weight | 6000kg | Certification | CE SGS | |
| Warranty | one year freely | After-sales Service Provided | Overseas service center available |
Product Description
1. Product Name:
LZ8/600 Straight wire drawing machine
2. Equipment composition:
(1) LZ8/600 Straight wire drawing machine
(2) Human-machine interface display
(3) full set of electrical control cabinet
3. Operating range:
(1) Max diameter: 6.5 mm
(2)Max. inlet strength: 700Mpa
(3) Drawing Material: stainless steel wire, etc. 304 314
(4) Min. outlet diameter: 2.0 mm
4. Drawing speed:
(1) Maximum speed: 7 m / s
(2) Nomal speed: 5 m / s
5. Water and air pressure:
(1) Water pressure> 0.2Mpa
(2) Air pressure> 0.5Mpa
6. Electrical Specifications:
(1) Drawing machine: 30KW AC inverter motor
(2) Take-up machine: 15KW AC inverter motor
7
