Home > Products > Air Chamber > Brake Chamber T24/30
Brake Chamber T24/30
US$ 6.8 - 21.5
/ Piece
50 Pieces(Min. Order)
- Xiamen Qingdao
- T/T Credit Card PayPal
You May Like
Product Details
| Type | Brake Assembly | Material | Steel, Alloy, Rubber, Rubber, Steel, Alloy | |
| Certification | ISO/TS16949 | Size | Internation Standard, T24/30DD | |
| Car Make | All trucks and Trailers | Place of Origin | Fujian, China | |
| Brand Name | TINMY | Model Number | T24/30DD |
Product Description
Specifications
Brake Chamber:1)Type:Single & Double Room Chamber
2)Size:T16,T20,T24,T30, T2024,,T2430,T3030
3)Certificate:ISO/TS16949
Brake Chamber T24/30DD :
1)Type:Single &Double Room Air Brake Chamber
2)Size:T12,T16,T20,T24,T30, T2024,T2424,T2430,T3030
3)Certificate:ISO/TS16949
Single Room Air Chamber :
| Item No. | Stroke | R1 | R2 | L1 | L2 | L4 | Push Rod Thread | Air Inlet Thread | Mounting Bolt Thread | Weight |
| mm | mm | mm | kg | |||||||
| TMC-T2024 | 64 | 110 | 88 | 220±5 | 75±5 | 50±4 | M16*1.5 | M16*1.5 | M16*1.5 | 7.78 |
| TMC-T2424 | 64 | 116 | 93 | 224±5 | 240±5 | 206±4 | 5/8"-18UNF2A | 3/8"-18NPTF | 5/8-11UNC2A | 8.1 |
| TMC-T2430 | 64 | 163 | 184 | 234±5 | 240±5 | 206±4 | 5/8"-18UNF2A | 3/8"-18NPTF | 5/8-11UNC2A | 9.2 |
| TMC-T3030 | 64 | 125 | 105 | 238±5 | 285±5 | 255±5 | 5/8"-18UNF2A | 3/8"-18NPTF | 5/8-11UNC2A | 9.5 |
Double Room Brake Chamber :
| Item No. | Stroke | R1 | R2 | L1 | L2 | L4 | Push Rod Thread | Air Inlet Thread | Mounting Bolt Thread | Weight |
| mm | mm | mm | kg | |||||||
| TMC-T09 | 44.5 | 87 | 68 | 104±5 | 106±5 | 130±3 | 1/2"-20UNF | 1/4"-18NPTF | 7/16"-14UNC | 1.9 |
| TMC-T12 | 44.5 | 125 | 105 | 104±5 | 160±5 | 130±3 | 1/2"-20UNF | 3/8"-18NPTF | 7/16"-14UNC | 2.3 |
| TMC-T16 | 57 | 107 | 83 | 109±3 | 163±5 | 160±3 | 1/2"-20UNF | 3/8"-18NPTF | 7/16"-14UNC | 3 |
| TMC-T20 | 57 | 11 | 88 | 84±5 | 240±5 | 200±4 | 5/8"-18UNF2A | 3/8"-18NPTF | 5/8-11UNC2A | 4 |
| TMC-T24 | 64 | 116 | 93 | 123±5 | 240±5 | 206±4 | 5/8"-18UNF2A | 3/8"-18NPTF | 5/8-11UNC2A | 4.1 |
| TMC-T30 | 64 | 125 | 105 | 123±5 | 285±5 | 255±4 | 5/8"-18UNF2A | 3/8"-18NPTF | 5/8-11UNC2A |
