Home > Products > Air Chamber > Truck Trailer Spring Chamber/Air Brake Chamber/Air Chamber
Truck Trailer Spring Chamber/Air Brake Chamber/Air Chamber
US$ 6 - 19
/ Piece
30 Pieces(Min. Order)
- Xiamen Shanghai
- T/T Credit Card PayPal
You May Like
Product Details
| Type | Brake Cylinders | Material | high quality steel, rubber. | |
| Certification | TS16949, ISO | Size | international standard | |
| OE NO. | internaitonal standard | Brand Name | Tinmy |
Product Description
Truck Trailer Spring Chamber/Air Brake Chamber/Air Chamber :
1.Size:T24,T30,T24T30,T3030,etc.
2.Single&double room.
3,DP & DD
4,Delivery time: Within ten days after receive T/T payment or L/C.
Tinmy can manufacture various air chamber (brake chamber) with high quality and competitive price.
Tinmy Spring Brake Chamber, Air Brake Chamber, Single room air chamber, double brake chamber
have been supplying to many countries in the world.
Single Room:
| Item No. | Stroke | R1 | R2 | L1 | L2 | L4 | Push Rod Thread | Air Inlet Thread | Mounting Bolt Thread | Weight |
| mm | mm | mm | kg | |||||||
| TMC-T2024 | 64 | 110 | 88 | 220±5 | 75±5 | 50±4 | M16*1.5 | M16*1.5 | M16*1.5 | 7.78 |
| TMC-T2424 | 64 | 116 | 93 | 224±5 | 240±5 | 206±4 | 5/8"-18UNF2A | 3/8"-18NPTF | 5/8-11UNC2A | 8.1 |
| TMC-T2430 | 64 | 163 | 184 | 234±5 | 240±5 | 206±4 | 5/8"-18UNF2A | 3/8"-18NPTF | 5/8-11UNC2A | 9.2 |
| TMC-T3030 | 64 | 125 | 105 | 238±5 | 285±5 | 255±5 | 5/8"-18UNF2A | 3/8"-18NPTF | 5/8-11UNC2A | 9.5 |
Double Room:
| Item No. | Stroke | R1 | R2 | L1 | L2 | L4 | Push Rod Thread | Air Inlet Thread | Mounting Bolt Thread | Weight |
| mm | mm | mm | kg | |||||||
| TMC-T09 | 44.5 | 87 | 68 | 104±5 | 106±5 | 130±3 | 1/2"-20UNF | 1/4"-18NPTF | 7/16"-14UNC | 1.9 |
| TMC-T12 | 44.5 | 125 | 105 | 104±5 | 160±5 | 130±3 | 1/2"-20UNF | 3/8"-18NPTF | 7/16"-14UNC | 2.3 |
| TMC-T16 | 57 | 107 | 83 | 109±3 | 163±5 | 160±3 | 1/2"-20UNF | 3/8"-18NPTF | 7/16"-14UNC | 3 |
| TMC-T20 | 57 | 11 | 88 | 84±5 | 240±5 | 200±4 | 5/8"-18UNF2A | 3/8"-18NPTF | 5/8-11UNC2A | 4 |
| TMC-T24 | 64 | 116 | 93 | 123±5 | 240±5 | 206±4 | 5/8"-18UNF2A | 3/8"-18NPTF | 5/8-11UNC2A | 4.1 |
| TMC-T30 | 64 | 125 | 105 | 123±5 | 285±5 | 255±4 | 5/8"-18UNF2A | 3/8"-18NPTF | 5/8-11UNC2A | 4.8 |
