Film product line:SJ mulching film blown machine set
Negotiable
/ Set
1 Set(Min. Order)
- Qingdao
You May Like
-
Film line of production:SS-DM Two Colors Film Series Blowing Machine Set
-
Film production line:Large-scale Expanded Geomembrane Machine Set
-
Film manufacturing:Large-scale Expanded Geomembrane Machine Set
-
Bst seller LD2800-I Wide-range Greenhouse Film Machine Set
-
Hengxiang Best seller Electrical Machine Wide-range Greenhouse Film Machine Set
-
Hengxiang Sell worldwide LD2800-I Wide-range Greenhouse Film Machine Set
Product Details
| Condition | New | Product Type | Other, agricultural film | |
| Place of Origin | Shandong, China | Brand Name | Hengxiang | |
| Model Number | LD100/LD1300/LD1600/LD2200/LD2500/LD2650/LD2800 | Certification | ISO9001 | |
| Warranty | one year | After-sales Service Provided | Overseas service center available |
Product Description
Specifications
1.High -property2.Low air pressure
3.Large air volume
Product Description
»Features amd application
1. The die head adopts advanced central head feeding spiral runner molding technology.
2. Molding and cooling of the film adopts air blower and air ring with high-property ,low air pressure, and large air volume.
3. The extruder adopts corrugated screw with oblique barrier and mixing head,which assures stable and reliable performance, high output and low energy consumption.
4. It adopts friction type double surface wind-up, which has improved the flatness of the film,and made the coiling structure tight. It is easier to operate. A length metering device is intalled, which makes the length of the film is accurate.
5. The electrical components are domestic famous brand, which realizes one panel control.
Technical parameters
| Model | LD1100 | LD1300 | LD1600 | LD2200 | DD2500 | LD2650 | LD2800 |
| Max.folding width of film(mm) | 1,000 | 1,200 | 1,500 | 2,000 | 2,300 | 2,500 | 2,600 |
| Max.folding width of film (mm) | 800 | 1,000 | 1,300 | 1,800 | 2,100 | 2,300 | 2,400 |
Ground film thickness (mm) | 0.003-0.009 | ||||||
| Farm film thickness (mm) | 0.04-0.08 | ||||||
| Outputs(kg/h) | 50 | 52 | 110 | 130 | 180 | 220 | 240 |
| Applicable meterial | LDPE,LLDPE,LDPE/LLDPE Blend | ||||||
| Screw diameter (mm) | 45 | 50 | 65 | 75 | 75 | 90 | 90 |
| L/D of screw | 30 | 28 | 28 | 28 | 30 | 30 | 30 |
| Max. rotating speed of screw | 130 | 130 | 140 | 105 | 110 | 120 | 120 |
| Type of the main motor | Can be matched by the requirements of the customer | ||||||
| Power of main motor(KW) | 15 | 18.5 | 37 | 45 | 55 | 75 | 90 |
| Die head type | Spiral die head | ||||||
| highest speed for ground film coiling(m/min) | 120 | 120 | 120 | 120 | 100 | 80 | 80 |
| highest speed for farm film coiling(m/min) | 30 | ||||||
| Total power | 28 | 32.5 | 72 | 80 | 88 | 105 | 180 |
| Overall dimensions(m) | 6.2×2.3× 5 | 6.4×2.5× 5 | 6.6×3 × 6.8 | 7.5×2.5× 7.7 | 7.8×3.2× 10.5 | 8×3.5 × 10.5 | 13×4× 9 |
| Weight(Tons) | 5.2 | 5.5 | 6.5 | 8.5 | 16 | 19.5 | 21 |
