Hengxiang Hot Sale Agricultural Film Machinery

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Product Type	Other, agricultural film
Place of Origin	Shandong, China	Brand Name	Hengxiang
Model Number	LD100/LD1300/LD1600/LD2200/LD2500/LD2650/LD2800	Certification	ISO9001
After-sales Service Provided	Overseas service center available

1.High output
2.Labor saving
3.Stable running

»Features amd application

1. The die head adopts advanced central head feeding spiral

runner molding technology.

2. Molding and cooling of the film adopts air blower and air

ring with high-property ,low air pressure, and large air volume.

3. The extruder adopts corrugated screw with oblique

barrier and mixing head,which assures stable and reliable

performance, high output and low energy consumption.

4. It adopts friction type double surface wind-up, which has

improved the flatness of the film,and made the coiling structure

tight. It is easier to operate. A length metering device is intalled,

which makes the length of the film is accurate.

5. The electrical components are domestic fanous brand,

which realizes one panel control.

Technical parameters

Model	LD1100	LD1300	LD1600	LD2200	DD2500	LD2650	LD2800
Max.folding width of ground film(mm)	1,000	1,200	1,500	2,000	2,300	2,500	2,600
Max.folding width of farm film (mm)	800	1,000	1,300	1,800	2,100	2,300	2,400
Ground film thickness (mm)	0.003-0.009
Farm film thickness (mm)	0.04-0.08
Outputs(kg/h)	50	52	110	130	180	220	240
Applicable meterial	LDPE,LLDPE,LDPE/LLDPE Blend
Screw diameter (mm)	45	50	65	75	75	90	90
L/D of screw	30	28	28	28	30	30	30
Max. rotating speed of screw	130	130	140	105	110	120	120
Type of the main motor	Can be matched by the requirements of the customer
Power of main motor(KW)	15	18.5	37	45	55	75	90
Die head type	Spiral die head
highest speed for ground film coiling(m/min)	120	120	120	120	100	80	80
highest speed for farm film coiling(m/min)	30
Total power	28	32.5	72	80	88	105	180
Overall dimensions(m)	6.2×2.3× 5	6.4×2.5× 5	6.6×3 × 6.8	7.5×2.5× 7.7	7.8×3.2× 10.5	8×3.5 × 10.5	13×4× 9
Weight(Tons)	5.2	5.5	6.5	8.5	16	19.5	21
