Made In China Toothbrush Monofilament Extrusion Line
- Shanghai
- T/T
You May Like
Product Details
| Condition | New | Application | Other, Toothbrush Monofilament Extrusion Line | |
| Plastic Processed | Other, PET | Screw Design | Single-screw | |
| Automatic Grade | Automatic | Place of Origin | Shanghai, China | |
| Brand Name | Toothbrush Monofilament Extrusion Line | Model Number | Toothbrush Monofilament Extrusion Line | |
| Voltage | 380V | Power(W) | 160kw | |
| Dimension(L*W*H) | 28000*2500*1970mm | Weight | 25 tons | |
| Certification | CE / ISO9001 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Toothbrush Monofilament Extrusion Line
1. Overview of Toothbrush Monofilament Extrusion Line
We have full experience in monofilament machine supplying. According to about 20 years experiences in this field, we have many many monofilament machines are in good production in all over the world.
Our monofilament machine can use virgin resin or recycled flakes of PP, PET as material to get very monofilament of good quality.
Monofilament can be used to make brush, broom, fishnet, zipper, string instrument.
2. Configuration of Toothbrush Monofilament Extrusion Line
No. | Part Name | Qty. | Introduction of Main Parts |
1 | Extruder | 1set | 1. Raw material: PET virgin or bottle flakes 2. Frequency conversion control speed. 3. Hard tooth surface gear motor: Jiangsu changzhou. 4. Screw and cylinder: Made in Zhejiang Zhoushan. 5. Material of screw heating: Al Casting. |
2 | Spinning die | 1pc | 1. Heating method of die head: oil heating. 2. Material of spinneret: SUS316. 3. Frequency conversion control speed, cycloidal pinwheel reducer.
|
3 | Cooling water tank | 1set | 1. Yarn separate pole is movable. 2. Material of box: stainless steel. |
4 | Seven roller Stretching A | 1set | 1. Frequency conversion control speed. Frequency conversion motor. 2. Steel structure of box, gear transmission, running balance. 3. In front, one rubber roller and stainless steel separate pole.
|
5 | Hot water tank | 1set | 1. Material is stainless steel with heat preservation, and cover is opened by gas 2. Heating method :electrical heating 3.Equip water recycling pump |
6 | Seven roller Stretching B | 1set | 1. Frequency conversion control speed Frequency conversion motor 2. Steel structure of box, gear transmission, running balance. 3. In front, one rubber roller and stainless steel separate pole
|
7 | Hot blast stretching recycled oven | 1set | 1. Single layer recycled hot blast oven 2. Equip wind power control 3. Hot blast path especial design make them equality 4. Frequency control of motor speed |
8 | Seven roller Stretching C | 1set | 1. Frequency conversion control speed Frequency conversion motor 2. Steel structure of box, gear transmission, running balance. 3. In front and back, each with one rubber roller and stainless steel separate pole.
|
9 | Oiling unit | 1set | 1. Frequency conversion control speed Frequency conversion motor |
10 | Yarn guider system | 1set |
|
11 | Winder | 2sets | Frame style winder |
12 | Cabinet | 1set | Shown in another list |
3. Pictures of Toothbrush Monofilament Extrusion Line

• We design, engineer and manufacture and customized the extrusion line.
• Choosing the right solution: In plastics manufacturing, process is everything. We carefully evaluate each project's requirements, weigh the options and recommend the best solution for the client.
• Training & Development: we offer extensive start-up assistance, comprehensive training. As well as Engineers for training and installation at our client’s factory
• Support: We support the client in all the stages of the project life cycle, as well as the constant spare parts supply in a time efficient manner.
At CissCo, we design, engineer and manufacture customized Toothbrush filament plant. There is a proven CissCo technology for virtually every extrusion line application. Our extensive knowledge of the industry - its raw materials, processes and finished products - provides reliability, cost optimization and on-time delivery, the same benefits that you would expect from proven pre-engineered components, all in a system designed and tailored to your unique requirements.
To ensure the efficiency, productivity and safety of our systems, we offer extensive start-up assistance, comprehensive training and operator manuals. When you have service needs, you can count on an immediate response from your nearest CissCo facility, one of many we have located strategically throughout the world. we are using the high technology from European. From the pictures, you can find the similarity between our machine and theirs.
