Small Shaping Machine BC6085
- 300 Piece / Pieces per Month
- Shenzhen
- T/T Credit Card
You May Like
Product Details
| Condition | New | Place of Origin | Guangxi, China | |
| Brand Name | Xiashi | Model Number | BC6085 | |
| Dimension(L*W*H) | 4140*1550*1850mm | Weight | 4600kg | |
| Warranty | 1 years | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Model | BC6085 | |
Maximum cutting length(mm) | 850 | |
Maximum distance from ram bottom to table surface(mm) | 400 | |
Maximum table horiziontal travel(mm) | 710 | |
Maximum table vertical travel(mm) | 360 | |
Dimensions of table top surface(L*M) (mm) | 800*450 | |
Travel of tool head(mm) | 160 | |
Swivel of tool head(?) | ±60? | |
Number of ram strokes per minute | 17,24,35,50,70,100 | |
Range of table power feed | Horizontel(mm) | 0.25~3? 12 |
Vertical(mm) | 0.12~1.5? 12 | |
Rapid feed of table | Horizontel(mm) | 1.2 |
Vertical(mm) | 0.58 | |
Width of central T-slot of table(mm) | 22 | |
Power of motor(kw) | 5.5 | |
Overall dimensions(L*W*H) (mm) | 2950*1352*1693 | |
Weight(kg) | 2940 | |
