Product Details
| Place of Origin | Zhejiang, China | Brand Name | FYCG | |
| Model Number | YP-S51 |
Product Description
YP-S51 28kHz Ultrasonic Water Treatment System
The cavitation effect of ultrasonic power for the realization of the degradation of toxic organic compounds provides physical and chemical environment unique resulting ultrasonic sewage treatment purposes. High energy enough to break chemical bonds of ultrasonic cavitation bubble collapse generated. In aqueous solution, the cavitation bubble collapsing to produce hydroxyl and hydrogen radical, oxidation reaction with organic matter. Open up new ways of chemical reaction of physical and chemical environment unique cavitation, increased the rate of chemical reaction, have strong ability to degrade organic matter, through continuous ultrasound can be harmful organic matter degradation as a matter of inorganic ions, water, carbon dioxide or organic acids.
| Model | YP-S51 | YP-S53 | YP-S55 | YP-S57 | YP-S59 | YP-S61 |
| Frequency | 28 kHz | 20 kHz | 20 kHz | 20 kHz | 20 kHz | 20 kHz |
| Power | 1000 W | 500 W | 1000 W | 1500 W | 2000 W | 3000 W |
| Voltage | 220±10% V | |||||
| Temperature | 300 °C | |||||
| Pressure | 30 MPa | |||||
| Intensity of sound | ≥15 W/cm² | ≥10 W/cm² | ≥20 W/cm² | ≥30 W/cm² | ≥40 W/cm² | ≥60 W/cm² |
| Capacity | 400 L/H | 300 L/H | 600 L/H | 900 L/H | 1200 L/H | 1800 L |
| Generator | V5.0 | V6.0 | V6.0 | V6.0 | V6.0 | V6.0 |
| Material of Horn | Titanium alloy | |||||
| Size | Generator: 200*420*280 mm Horn:Standard or Custom Made | Generator: 400*430*190 mm Horn:Standard or Custom Made | Generator: 400*430*190 mm Horn:Standard or Custom Made | Generator: 400*430*190 mm Horn:Standard or Custom Made | Generator: 400*430*190 mm Horn:Standard or Custom Made | Generator: 400*430*190 mm Horn:Standard or Custom Made |
The technology of ultrasonic degradation of organic pollutants in water can be used alone, also can use the ultrasonic cavitation, ultrasonic degradation technology with other processing techniques used to degrade organic pollutants removal.
- Ultrasonic and ozone combined with interaction, ultrasonic degradation, sterilization and ozone disinfection treatment to polluted water.
- Ultrasonic with hydrogen peroxide combined with, in order to reach purpose of degradation of contaminated water, sterilization, disinfection.
- The ultrasonic and ultraviolet spectrometry, chemical composition of photoacoustic technique using ultrasonic technique and UV technology to their degradation ability superimposed cooperative and complementary role of organic pollutants in water, phenol, common four hydrogenated carbon, three hydrogen methane and three chloroacetic acid degradation, the four substances falling short chain fatty hydrolysate as carbon dioxide, water, C1- or readily biodegradable acid.
- Ultrasonic and magnetic treatment technique, the magnetization of water can not only realize solid-liquid separation, and degradation of COD, BOD and other organic matter, can also be used for decolorization of dyeing water.
- Ultrasonic can also be directly used as auxiliary technology of traditional chemical sterilization treatment, in the traditional chemical method for large-scale water treatment, increasing the ultrasonic radiation, can greatly reduce the usage of chemical agent.
- Hangzhou Success Ultrasonic Equipment Co.,Ltd is the leader of high-power ultrasonic equipment in China.
- Our company was founded in 1978.We have more than 30 years experiences.
- We have more than 20 engineers.They can make design scheme according to your requirements.
- Our piezoeletric ceramic disc is imported from Germany.The transducer have longer service life.
- Welcome to send us your sample.We have an open laboratory.It is free for making experiment.And we will take a video for you.
- We are specializing in high-power ultrasonic device and approved by CE, BV, ISO 9001.
- 24 hours technical supports and after-sales service
- Non-human damage, one year guaranteed exchange, three years warranty
