Home > Products > Beam house tannery machine > Tannery Machines Italy Quality 1500mm Hydraulic Leather Fleshing Machine
Tannery Machines Italy Quality 1500mm Hydraulic Leather Fleshing Machine
- Shanghai
- T/T
You May Like
-
Leather Tannery Machine Italy Quality 1500mm Hydraulic Leather Fleshing Machine
-
Italy Quality1500mm Leather Tannery Machine Fleshing Machine
-
Italy Quality 1500mm Hydraulic Leather Fleshing Machine
-
Fleshing Machine for Sale Italy Quality 1500mm Hydraulic Leather Fleshing Machine
-
Leather Tannery Machine Used Fleshing Machines Leather Process Machine
-
Tannery Machine China DCH China Best Hydraulic Leather Fleshing Machine
Product Details
| Condition | New | Automatic Grade | Automatic | |
| Place of Origin | Jiangsu, China | Brand Name | DCH | |
| Model Number | for tannery machines | Type | Other, for tannery machines | |
| Voltage | 380v/3phase | Power(W) | 25kw | |
| Dimension(L*W*H) | 2500X3400X3000mm | Weight | 2500kg | |
| Certification | CE | Warranty | 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
tannery machines1.special goat or sheep leather
2.hydraulic control
3.auto grind the blade
for tannery machines key point :
1.hydraulic system fleshing machine
2.stainless steel machinery structure
3.special for cow cattle buffalo and so on
4.one system for control two sets machine running together
5.auto balance unit Rubber rod pallet for keep difference thickness skin get good finally quality
6. rhombic channel roller ensure skin never move during running
7.double times auto protect system
9.auto grinder for blade
for tannery machines pecification :
Working width (mm) | 2200 | 2700 | 3200 |
O/D of blade cylinder | 260 | 260 | 260 |
Speed of blade cylinder | 1480 | 1480 | 1480 |
Main motor (KW) | 45 | 45 | 55 |
Pump pressure (bar) | 40-45 | 40-45 | 40-45 |
Feed speed (m/min) | 19-50 | 19-50 | 19-50 |
Oil pump motor (Kw) | 11 | 11 | 15 |
Capacity(pc/h) | 120-150 | 120-150 | 120-150 |
Outline (LxWxH) (mm) | 4400x1540x1600 | 4900x1540x1600 | 5400x1540x1600 |
Net weight (KG) | 7200 | 7850 | 9000 |
for tannery machines warrantee time :
one year after machinery arrive in buyer factory ,during one year ,if machinery part damage except by person, factory free change ,but transport charge paid by buyer
for tannery machines installation :
free install within one week ,but visa charge, tickets go and back, hotel and food will be arranged by buyer.
