2015 Hot Sale New Designed Small Volume Concrete Mixer Truck

FOB Price

US$ 23,500 - 31,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Hubei, China
Brand Name	FuTian	Model Number	BJ5143GJB-1
Motor Power	96Kw	Mixing Power	ref as below detail
Charging Capacity	ref as below detail	Reclaiming capacity	ref as below detail
Speed of Mixing Drum	ref as below detail	Water Supply Mode	ref as below detail
Working Cycle Period	ref as below detail	Discharge Way	ref as below detail
Outline Dimension	646022553300	After-sales Service Provided	Overseas third-party support available

2015 Hot Sale New Designed Small Volume Concrete Mixer Truck

Product Description

1.running stable

2.quality reliable
3.inner environmental comfortable
4.energy efficient
5.famous brand chassis

Main specifications
Product model,name	BJ5143GJB-1 CONCRETE MIXER TRUCK
Total weight(Kg)	13570		Tank capacity (m3)			5m³
Payload (Kg)	7460,6640		Overall dimension (mm)			6460×2255×3300
Curb weight(Kg)	5980
cab seats (man)	2
Approach/departure angle (°)	24/20		Front/rear hang(mm)			1230/1830
Number of axles	2		Wheelbase(mm)			3400
Axle load(Kg)	4610/8960		Max speed(Km/h)			83
Chassis specifications
Chassis model		BJ1143VJPFA-1		Chassis category		the truck classis (class 2)
Brand name		FOTON		Manufacture		Foton motor co.,ltd
Overall dimension(mm)		6070×2180×2510		Tires No.		6
Approach/departure angle (°)		24/22		Tire specification		8.25-20
Steel spring number		10/12+9		Front track(mm)		1774
Type of fuel		Diesel		Rear track(mm)		1669
Emission standard		GB17691-2005 Euro Ⅲ,GB3847-2005
Chassis model		Engine manufacture			Displacement(ml)		Power(Kw)
YC4D130-33		Guangxi yuchai machinery co.,ltd			4214		96
Special functions
We company specializes in development, design, manufacture of concrete mixer truck, using advanced optimization design of tank, logarithmic spiral die forming three-dimensional mixing blades, discharging quickly and no residual. Adopt international famous brand reducer, hydraulic pump, motor, reliable performance,high working efficiency, and ensure the overall quality and service life. The truck is widely used in building construction enterprises.

Vehicle Model: FOTON 4x2 Concrete Mixer Truck WITH 3-5CMB CONCRETE MIXER TRUCK FOR SALES

ProductImage:

Our company Detail:

Production equipment introduction
