YTO Rough Terrain Forklift 1.5T TC4015

                                                           Speciality parameter

 Model

Unit

TC4015

Power type

 Diesel

Rated capacity

kg

1500

Load center

d

mm

500

Lift height

h2

mm

3300

Mast tilt angle (forward/backward)

α/β

Deg

6/12

Wheel-base

L4

mm

1968

Tread(front/rear)

b4/b5

mm

1350/1330

                                         Performance               parameter

Travel brake

Mechanical-Foot pedal

Parking brake

Mechanical-Hand level

Lift speed(with/without load)

mm/s

420/450

Lower speed (with/without load)

mm/s

(with load)<380 ,(without load)>330

Travel speed (with/without load)

km/h

23/25

Max. gradeability (with load)

%

20

Power, transmission and others

                  Engine

Model

C490BT

Manufacturer

Xinchang

Rated power

kw

29.4/2400

Max.  rotation

Nm/rpm

146/1650

                        Battery

Voltage

V

12

Capacity

Ah

100

                       Gearbox

Transmission type

Mechanical

Gears,speed (front/rear)

8/8

                           Tyre

 type

Tubeless Tires

                     Model

Front

12.5/80-18TL-12PR

Rear

5.70-12TL-6PR

                                  Others

Self.weight

kg

2980

Fork

Thickness×Width×Length

c×b×a

mm

35*100*920

Overall dimensions

Overall length(without forks)

L2

mm

4410/3490

Overall width

b1

mm

1665

Lower height(mast)

h3

mm

2300

Overhead guard

h7

mm

2245

Min. turning radius

Wa

mm

4050

Min. under ground clearance

Under mast

m1

mm

250

Center of wheel-base

m2

mm

250
