China Professional Rotary Valve for Powder Feeder

Specification

1. The Structure of rotary valve is simple,small volume.

2. Convenient install and maintain.

3. Uniform feeding.

4. ISO,TUV,SEW.FLENDER.

  China professional rotary valve for powder feeder

Operating Principle

Rotary valve for powder feeder is also known as the rotary valve, star feeder, star discharging valve material, star unloader, star valve, rotary valve, ash discharge valve and so on. For uniform discharge or uniform feeding device in a variety of occasions, It is mostly installed under the Silo to discharge.

Main Feature

*It has excellent performance through the pressure seal.

*Rotary airlock feeder (rotary valve) has the function of quantitative feeding.

*We provide 50 ~ 750mm of various size, various materials.

*The various dimensions of the aperture, can provide square or round flanged connection.

*Standard type gear motor drive (or chain driven), can choose frequency controlled .

*Superior performance, durable rotary valve.

Components

Site picture

Technical parameter

Packaging and shipping of Uniform feeding rotary airlock valve price

1. Export packing.(Wooden case, carbon cast and pallet).

2. Container (as customer requirements)

3. It is suitable for long distance ocean transportation.

Our service

I.  Engineers abailable to service machinery overseas.

2. Provide installation guide, equipment manuals,  operation and repair training.

3. Provide random spare parts.

FAQ of Rotary valve for powder feeder

Please tell us the following technical parameters before inquiry:

Q: What 's the material will be conveyed?please tell us more material features.

Q: What's the up and lower flange dimension of rotary valve?

Q:What's the conveying capacity do you want?

Company certificate

Processing equipments

Other information

Welcome to consult us for more information.
