Rotary Kiln Cooling Machine for Cement Rotary Calcining System
- Shanghai Tianjin Qingdao
- T/T
You May Like
Product Details
| Place of Origin | Henan, China | Brand Name | GMG cement rotary cooler | |
| Model Number | various | Condition | New | |
| After-sales Service Provided | No overseas service provided |
Product Description
Specifications
rotary kiln cooler machine1.high capacity
2. High cooling efficiency
3. Reliable performance
4. Energy-saving
Specifications:
rotary kiln cooling machine for cement rotary calcining system
1.ISO9001:2008, ce certification
2.First Class Service
3.Fast delivery and best after-sale service
4.simple structure, stable performance, reliable operation
Brief Introduction of rotary kiln cooling machine for cement rotary calcining system:
Name: rotary kiln cooling machine for cement rotary calcining system
Cooler is divided into grate cooler and single-cylinder cooler. The grate cooler is one kind of quench cooler.
And the single-cylinder cooler is important equipment in rotary kiln system.
The Working Process and Funtion Features of rotary kiln cooling machine for cement rotary calcining system
The function of the cooler is to help clinker (1000°C-1200°C) from the rotary kiln make full heat exchange with air through rotation of the cylinder body.
In this way, clinker will be cooled down below 200°C, and the quality and grindality of the clinker will be improved.
After the materials are cooled, the air enters into kiln and be used as secondary circulating air, which improves the thermal efficiency of kiln. It can efficiently improve the material’s grindability and reduce the grinding power consumption. It is an important supporting device of rotary kiln.
Application of rotary kiln cooling machine for cement rotary calcining system:
A Cement Clinker Rotary Cooler is usually used to be matched with rotary calciner and rotary drier as the complete priduction plant.
This series of cooling machine is widely used in construction stuff, chemical, metallurgic industries for cooling all kinds of materials. It is applicable for cooling materials like slag, limestone, coal powder, and clay, etc.
Technical Data of rotary kiln cooler machine for cement plant:
| Specification | Output | Rotating speed of cylinder | Cylinder slope | Main motor | Main speed reducer | Weight | |
| Model | Power | ||||||
| 1.2×10 | 3.0-5.0 | 4.0 | 2.5° | Y132M-4 | 7.5 | ZL40 | 10.0 |
| 1.4×12 | 4.0-6.0 | 3.3 | 2.5° | Y160L-6 | 11.0 | ZL60-40 | 15.8 |
| 1.5×14 | 5.0-10 | 3.3 | 2.5° | Y180L-6 | 15.0 | ZL70 | 19.5 |
| 1.6×16 | 5.5-11 | 3.5 | 2.5° | Y300L-4 | 18.5 | ZSY200-22.4 | 21.5 |
| 1.8×14 | 6.0-12 | 3.1 | 2.5° | Y200L1-6 | 18.5 | ZSY200-40 | 24.5 |
| 1.8×18 | 6.5-13 | 3.1 | 2.5° | Y225M-6 | 22.0 | ZL75-25-Ⅱ | 28.8 |
| 2.0×16 | 7.0-14 | 3.16 | 2.5° | Y255M-6 | 22.0 | ZL85-25-Ⅱ | 36.5 |
| 2.0×20 | 7.5-15 | 3.16 | 2.5° | Y280S-6 | 30.0 | ZL85-25-Ⅱ | 42.0 |
| 2.2×18 | 7.5-15 | 3.0 | 2.5° | Y280S-6 | 45.0 | ZSY250-35.5 | 45.8 |
| 2.2×22 | 8.0-16 | 3.0 | 3.5% | Y280S-6 | 45.0 | ZSY250-35.5 | 48.0 |
| 2.4×18 | 9.0-18 | 4.9 | 2.5° | Y225M-4 | 45.0 | ZSY250-31.5 | 56.5 |
| 2.4×22 | 10-20 | 3.6 | 2.5° | Y280M-6 | 55.0 | ZSY315-31.5 | 63.0 |
| 2.4×26 | 11-22 | 3.6 | 2.5° | Y315S-6 | 75.0 | ZSY315-31.5 | 69.0 |
| 2.6×24 | 12-24 | 3.6 | 2.5° | Y315S-6 | 75.0 | ZSY315-31.5 | 72.5 |
| 2.6×26 | 14-28 | 3.1 | 2.5° | Y315M-6 | 90.0 | ZSY315-31.5 | 81.0 |
| 2.8×24 | 15-30 | 3.1 | 2.5° | Y315S-6 | 75.0 | ZSY315-31.5 | 90.6 |
| 2.8×28 | 16-32 | 3.1 | 2.5° | Y315M-6 | 90.0 | ZSY315-31.5 | 96.5 |
| 3.0×24 | 20-40 | 3.05 | 2.5° | Y315M-6 | 90.0 | ZSY315-31.5 | 92.6 |
| 3.0×28 | 22-45 | 5.9 | 3.5% | Y315M-6 | 90.0 | ZSY315-31.5 | 108.0 |
| 3.0×30 | 25-50 | 3.85 | 3.5% | Y315S-4 | 110 | ZSY355-35.5 | 112.0 |
| 3.2×26 | 25-50 | 3.85 | 3.5% | Y315S-4 | 110 | ZSY355-35.5 | 125.0 |
| 3.2×28 | 28-55 | 3.47 | 2.5° | Y315L2-6 | 132 | ZSY355-35.5 | 132.0 |
| 3.4×28 | 30-60 | 3.47 | 2.5° | Y355M1-6 | 160 | ZSY400-35.5 | 156.6 |
| 3.4×30 | 32-65 | 3.47 | 2.5° | Y355M1-6 | 160 | ZSY400-35.5 | 166.0 |
| 3.6×32 | 35-70 | 4.95 | 3.5% | Y315M-4 | 185 | ZSY500-35.5 | 175.0 |
| 3.6×36 | 38-75 | 4.95 | 3.5% | Y355S2-4 | 200 | ZSY500-35.5 | 185.0 |
| 3.8×30 | 40-80 | 3.18 | 2.5° | Y355S2-4 | 200 | ZSY500-35.5 | 206.0 |
| 4.0×32 | 45-90 | 3.18 | 2.5° | Y355L-6 | 220 | ZSY500-31.5 | 215.0 |
| 4.0×34 | 50-100 | 3.0 | 2.5° | YJS355L-6 | 250 | ZSY500-35.5 | 230.0 |
