80-100 T/hour Large Capacity Cement Mill for Cement Grinding Plant
- SHANGHAI
You May Like
-
100-200 T/hour Large Capacity Cement Mill
-
50-150 T/hour Large Capacity Cement Mill
-
15-20 T/hour Raw Meal Grinding Ball Mill for Cement Grinding Plant
-
15-25 T/hour Raw Meal Grinding Ball Mill for Cement Grinding Plant
-
30-45 T/hour Raw Meal Grinding Ball Mill for Cement Grinding Plant
-
0.5-45 T/hour Raw Meal Grinding Ball Mill for Cement Grinding Plant
Product Details
| Condition | New | Type | Ball Mill | |
| Motor Type | AC Motor | Power(W) | acording to the capacity | |
| Capacity(t/h) | 80-100 t/h | Place of Origin | Henan, China | |
| Brand Name | GMG | Model Number | acording to the capacity | |
| Dimension(L*W*H) | acording to the capacity | Weight | acording to the capacity | |
| Certification | ce and iso | Warranty | all life | |
| After-sales Service Provided | No overseas service provided |
Product Description
Specifications
1.directly manufacturer2.with low price spare parts
3.any capacity
80-100 t/hour large capacity cement mill
Grinding ball mill is widely used for the cement production line, cement plant, cement grinding plant to grinding limetstone, cement raw materials and cement clinker. It is an essential cement making machinery in the cement production process.
There are two ways of grinding: the dry way and the wet way. It can be divided into tabular type and flowing type according to different expelling mine.
Related: dry grinding ball mill, wet ball mill .Our engineers will suggest the most suitable one for you according to your information.
Working principle of cement mill:
Features of cement mill :
Structure of cement mill :
This Grinding Ball Mill is composed by feeding part, discharging part, rotation part and driving part (reducer, small driving gear, Lubrication and cooling device electric motor and electric control.
Technical Parameter of cement mill:
Specifications (m) | Capacity (t/h) Close Circuit / Open Circuit | Effective Volume (m3) | Feeding Size (mm) | Rotating Speed (r/min) | Load of Grinding Media (t) | Driving mode | Main Motor | Main Reducer | Weight (t) | ||
Type | Power | Type | Speed Ratio | ||||||||
ø1.83 x7.5 | 9.5-10.0 | 17.68 | ≤25 | 23.9 | 22.5 | Edge | JR138-8 | 245 | ZD60-8 | 4.5 | 40 |
Ø2.2X (6.5+1) (Dry) | 21-25 | 21.3 | ≤25 | 21.4 | 31 | Edge | JR15-88 | 380 | ZD70-9 | 5 | 50 |
Ø2.2 X13 | 34-38 | 42.4 | ≤25 | 21.4 | 58 | Edge | YR630-8 | 630 | ZD80 | 5 | 95 |
Ø2.4 X7 | 26-28 | 28.17 | ≤25 | 20.4 | 39 | Edge | JR1512-8 | 570 | ZD80 | 5 | 72 |
Ø2.4 X8 | 28-30 | 32.2 | ≤20 | 20.4 | 42 | Edge | JR1512-8 | 570 | ZD80 | 5 | 77 |
Ø2.4 X9 | 36-38 | 36.2 | ≤20 | 20.4 | 45 | Edge | JR1512-8 | 570 | ZD80 | 5 | 81 |
Ø2.4 X10 | (open)34-38 (close)40-44 | 40.3 | ≤20 | 20.91 | 50 | Edge | YR630-8 | 630 | MBY630 | 5 | 111 |
Ø2.4 X11 | (open)34-38 (close)44-47 | 43.4 | ≤20 | 20.91 | 58 | Edge | JR1512-8 | 630 | MBY630 | 5 | 125 |
Ø2.4 X12 | (open)40-42 (close)45-48 | 46.5 | ≤25 | 21.5 | 64 | Edge | YR800-8 | 800 | MBY710 | 6.3 | 126 |
Ø2.4 X13 | (open)42-44 (close)48-51 | 49.6 | ≤25 | 21.5 | 70 | Edge | YR800-8 | 800 | MBY710 | 6.3 | 130.6 |
Ø2.6X8.5 | 50-55 | 38.6 | ≤20 | 19.6 | 56 | Edge | YR630-8 | 630 | MBY630 | 5.6 | 110 |
Ø2.6X10 | 52-55 | 45.47 | ≤20 | 19.6 | 72 | Edge | YR1000-8 | 1000 | MBY710 | 5.6 | 140 |
Ø2.6X13 (Wet) | 50-55 | 60.5 | ≤25 | 19.11 | 80 | Edge | YR1000-8 | 1000 | MBY710 | 4.5 | 158 |
Ø3x9 | 55-60 | 58.5 | ≤25 | 18.98 | 85 | Edge | YR1000-8 | 1000 | MBY710 | 5.6 | 147 |
Ø3x (8.5+5) (Dry) | 58-62 | 61.5 | ≤25 | 18.98 | 82 | Edge | YR1000-8 | 1000 | MBY710 | 5.6 | 160 |
Ø3.2x9 | 70-75 | 62 | ≤25 | 18.3 | 90 | Edge | YR1250-8 | 1250 | MBY900 | 6.3 | 175 |
Ø3.5X8 | 75-80 | 68 | ≤25 | 17.1 | 91 | Edge | YR1250-8 | 1250 | MBY900 | 5.6 | 182 |
Ø3.5X10 (Dry) | 80-85 | 85 | ≤25 | 17.1 | 80 | Center | YR1400-8 | 1400 | MBYX 900 | 6.3 | 194 |
Ø3.6x (7.5+1.5) (Dry) | 95-100 | 83.7 | ≤25 | 17.05 | 85 | Edge | YR1400-8 | 1400 | MBY900 | 6.3 | 220 |
Ø3.8X7.5 (Air-swept) | 85-90 | 82 | ≤20 | 16.7 | 95 | Edge | YR1400-8 | 1400 | MBY800 | 5.6 | 182 |
Ø3.8X7.5 (Dry) | 85-90 | 82 | ≤20 | 16.7 | 103 | Edge | YR1400-8 | 1400 | MBY800 | 5.6 | 182 |
Ø3.8X12 (Dry) | 135-138 | 108.5 | ≤25 | 16.6 | 112 | Center | YR800-8 | 2000 | MFY 200A JS130-A |
| 295 |
Ø4.2x (8.5+2.5) (Dry) | 130-140 | 116 | ≤25 | 15.6 | 130 | Center double slide shoe | YRKK 900-8 | 2500 | MFY 250A JS130- C2 |
| 355 |
Ø4.2x (10+3.5) (Dry) | 150-160 | 130 | ≤25 | 15.1 | 160 | Center double slide shoe | YRKK 900-8 | 3150 | MFY 320A JS140-C |
| 400 |
Ø4.6x (9.5+3.5) (Dry) | 185-190 | 145 | ≤25 | 15.1 | 180 max | Center double slide shoe | YRKK 1000-8 | 3550 | MFY 355A JS150-B |
| 415 |
Ø4.6x (10+3.5) (Dry) | 190-200 | 160 | ≤25 | 15.1 | 190 max | Center double slide shoe | YRKK 1000-8 | 3550 | MFY 355A JS150-B |
| 423 |
Ø4.6x (11+3.5) (Dry) | 220-240 | 191 | ≤25 | 15.2 | 258 max | Center double slide shoe | YRKK 1000-8 | 4000 | MFY 400A JS160-B |
| 480 |
Spare parts of cement mill :
Transportaion and Installtation of Raw Meal Ball Mill Grinding Used for Cement Plant:
Certification of cement mill :
