Product Details
| Place of Origin | Zhejiang, China | Brand Name | Solis | |
| Model Number | Solis-2G-10K | Specification | Normal | |
| Application | Commercial | Output Voltage (V) | 380/400Vac | |
| Solar Power (W) | 10000W |
Product Description
On Grid Solar Inverter 10KW Triphase Grid Tied Inverter
for Poly and Mono Panel
Powerician, authorized distributor of Solis, supply full range of Solis solar inverter, from 700W to 30kW.
Also, we provide whole on-grid solar power system solution with Solis inverter and our high quality solar panles, brackets, wires etc.
Three Phase On Grid Solar Inverter 15kw Solis Brand Dual MPPT Inverter
Features
- Dual functional for both solar PV and wind turbine
- Extral wide input range
- Advancec MPPTalgorithm
- Full protection
- High efficiency
- RS485,GPRS,Wifi,mobile phone APP monitoring supported
Three Phase On Grid Solar Inverter 15kw Solis Brand Dual MPPT Inverter
Electrical Data
| Model No. | Solis-6K | Solis-10K | Solis-15K | Solis-20K-HV |
| Input | ||||
| Max Input Power | 6.9KW | 11.5KW | 15KW | 23KW |
Max Input Voltage | 1000V | |||
Start Voltage | 330V | |||
| MPPT Voltage | 200~800V | |||
| Max Input Current | 15A+15A | 18A+18A | ||
| MPPT/String | 2/2 | 2/4 | ||
| Output | ||||
| Rated Output Power | 6KW | 10KW | 15KW | 20KW |
| Max Output Power | 6.6KW | 11KW | 15KW | 20KW |
| Rate Grid Voltage | 380/400Vac | 480Vac | ||
| Grid Voltage Range | 313~470V Adjustable | 384~576V Adjustable | ||
| Rated Grid Frequency | 50/60Hz | |||
| Grid Frequency Range | 47~52Hz or 57~62Hz | |||
| Phase Quantity | 3 Phase | |||
| Max Output Current | 10.0A | 16.7A | 25A | 25.1A |
| Output Power Factor | >0.99 | |||
| THD | <3% | |||
| Grid DC Component | <20mA | <50mA | ||
| Max Efficiency | 98.2% | 98.3% | ||
| European Efficiency | 97.3% | 97.5% | ||
| MPPT Efficiency | 99.9% | |||
| Protection | ||||
| DC Reverse Connection | Yes | |||
| AC Short Circuit | Yes | |||
| AC Output Over Current | Yes | |||
| Output Over Voltage | Yes | |||
| Insulation Resistance | Yes | |||
| RCD Testing | Yes | |||
| Surge Protection | Yes | |||
| Grid Mornitoring | Yes | |||
| Anti-Island | Yes | |||
| Over Heat | Yes | |||
| Integrated DC Switch | Optional | |||
Basical Data
Three Phase On Grid Solar Inverter 15kw Solis Brand Dual MPPT Inverter
| Dimension | 430*600*220mm | |||
| Weight | 27kg | 30kg | ||
| Topology | Transformer Less | |||
| Self Consumption | <1W At Night | |||
| Working Environmental Temp. | -25~+60°C | |||
| Working Environ.Humidity | 0~95% | |||
| Protection Level | IP65 | |||
| Noise | <30dBA | |||
| Cooling | Natural convection | |||
| Max.Working Elevation | 2000m | |||
| Design Life Span | 20Years | |||
| Grid Connect Standard | EN50438,G83/2,AS4777,VDE0126-1- | |||
| Safty Standard | EN61000-6-1:2007,EN61000-6-3:2007,IEC62109-1/2;AS3100;NB/T32004 | |||
Interface
| DC | MC-4 Terminal |
| AC | IP67 Connector |
| Display | LCD 2*20Z |
| Communication | RS485,Wifi,GPRS(optional) |
Three Phase On Grid Solar Inverter 15kw Solis Brand Dual MPPT Inverter
Communication
WIF/ GPRS for single inverter
Three Phase On Grid Solar Inverter 15kw Solis Brand Dual MPPT Inverter
For more than one inverter
Three Phase On Grid Solar Inverter 15kw Solis Brand Dual MPPT Inverter
10KW Solar Inverter 3Phase 10KW Grid Tie Inverter for Business Solar Power
Three Phase On Grid Solar Inverter 15kw Solis Brand Dual MPPT Inverter
10KW Solar Inverter 3Phase 10KW Grid Tie Inverter for Business Solar Power
Three Phase On Grid Solar Inverter 15kw Solis Brand Dual MPPT Inverter
Three Phase On Grid Solar Inverter 15kw Solis Brand Dual MPPT Inverter
