Product Details
| Brand Name | GINLONG | Model Number | GCI-MINI-2000 | |
| Specification | Mini | Application | Home | |
| Output Voltage (V) | 220/230 | Solar Power (W) | 2000W |
Product Description
2000W String Inverter for Residential Rooftop On Grid Solar Inverter
Ginlong is a top brand solar inverter from China with high quality and excellent reliablility.
Powerician, authorized distributor of Ginlong, supply full range of Ginlong solar inverter, from 700W to 30kW.
Also, we provide whole on-grid solar power system solution with Ginlong inverter and our high quality solar panles, brackets, wires etc.
Product Description
Features
- Gene of wind power inverter, extral wide input range
- Small and light
- Advancec MPPTalgorithm
- Full protection
- High efficiency
- RS485,GPRS,Wifi,mobile phone APP monitoring supported
Electrical Data
ProtectionYesYes
Yes
| Model | Solis-MINI-700 | Solis-MINI-1000 | Solis-MINI-1500 | Solis-MINI-2000 |
| Input | ||||
| Max Input Power | 900W | 1200W | 1800W | 2400W |
| Max Input Voltage | 450V | 500V | ||
| Start Voltage | 60V | |||
| MPPT Range | 50-400V | |||
| Max Input Current | 10A | |||
| MPPT/Input | 1 MPPT 1 String Input | |||
| Output | ||||
| Rated Output Power | 700W | 1000W | 1500W | 2000W |
| Max Output Power | 800W | 1100W | 1650W | 2200W |
| Rated Grid Voltage | 220/230V | |||
| Grid Voltage Range | 180~270V(Adjustable) | |||
| Rated Grid Frequency | 50/60Hz | |||
| Working Frenq.Range | 47-52Hz or 57-62HZ Adjustable | |||
| Phase Number | Single Phase | |||
| Max.Output Current | 4.4A | 6.1A | 9.2A | 12.2A |
| Output Power Factor | >0.99 | |||
| THD | <3% | |||
Grid DC Component | <20mA | |||
| Max Efficiency | 96.7% | |||
| European Efficiency | 96.2% | |||
| MPPT Efficiency | 99.9% | |||
| Protection | ||||
| DC Reverse Connection | Yes | |||
| AC Short Circuit | Yes | |||
| AC Output Over Current | Yes | |||
| Output Over Voltage | Yes | |||
| Insulation Resistance | Yes | |||
| RCD Testing | Yes | |||
| Surge Power Protection | Yes | |||
| Grid Connection Mornitoring | Yes | |||
| Anti-Island | Yes | |||
| Over Heat Protection | Yes | |||
| Integrated DC Switch | Optional | |||
Basical Data
| Model Number | GCI-MINI-700 | GCI-MINI-1000 | GCI-MINI-1500 | GCI-MINI-2000 |
| Dimension | 270*417*124mm | |||
| Weight | 5.2kg | 5.6kg | ||
| Topology | Transformer Less | |||
| Self Consumption | <1W At Night | |||
| Working Environmental Temp. | -25~+60°C | |||
| Working Environ.Humidity | 0~95% | |||
| Protection Level | IP65 | |||
| Noise | <30dBA | |||
| Cooling | Natural convection | |||
| Max.Working Elevation | 2000m | |||
| Design Life Span | 20Years | |||
| Grid Connect Standard | EN50438,G83/2,AS4777,VDE0126-1- | |||
| Safty Standard | EN61000;-6-1:2007,EN61000-6-3:2007,IEC62109-1/2;AS3100;NB/T32004 | |||
Interface
| DC | MC-4 Terminal |
| AC | IP67 Connector |
| Display | LCD 2*20Z |
| Communication | RS485,Wifi,GPRS(optional) |
Communication
WIF/ GPRS for single inverter
For more than one inverter
