Home > Products > Other Products > PN 10/16 Cast Iron Pressure Reducing Valve
PN 10/16 Cast Iron Pressure Reducing Valve
- NINGBO/SHANGHAI
- T/T L/C D/P D/A Money Gram Credit Card
You May Like
Product Details
| Standard or Nonstandard | Other, standard,non-standard | Structure | Butterfly | |
| Pressure | High Pressure | Power | Hydraulic | |
| Material | Casting | Temperature of Media | High Temperature | |
| Media | Other, water,oil,acid | Port Size | 2"-24" (DN50-600) | |
| Model Number | 9501 | Brand Name | OEM | |
| Application | General |
Product Description
PN 10/16 cast iron pressure reducing valve
Product Specification:
1.Product Size: | DN50-1000 (2”-40”) |
2.Working Pressure: | PN10-16( 145-230 PSI) |
3.Actuator | Handle, worm gear, pneumatic or electric |
4.Standard: | DIN,BS,ISO,ANSI, |
5.Connection: | Flange type |
6.Working Temperature | -15~150 Degree |
7.Body Material | Cast iron, stainless steel or carbon steel available |
Seat Temperature Ratings
Material | NBR | Neoprene | EPDM | Hypalon | Viton | PTFE | |
Temperature Ratings | °C | -20~100 | -40~100 | -40~120 | -32~135 | -12~230 | -50~200 |
°F | -4~212 | -40~212 | -40~248 | -25.6~275 | 10.4~446 | -58~392 | |
Products Feature:
1.High strength, light weight, good seal
2.Easy installation and maintenance;
2.Simple compact structure and quick on-off operation;
3.Small operation torque, energy-saving
4. Strict opening and closing test , long service life
5. Applicable for water, steem, food, oil,acid,etc.
