Hot Sell Super Quality Gearbox Concrete Mixer
- China Port
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Henan, China | |
| Brand Name | UNIQUE | Model Number | JZC500 | |
| Mixing Power | 7.5kw | Charging Capacity | 800L | |
| Reclaiming capacity | 500L | Speed of Mixing Drum | 13r/min | |
| Outline Dimension | 3500x2200x3200mm |
Product Description
Specifications
Gearbox Concrete Mixer1.gear transmition,high efficiency
2.CE&ISO certificate,discharge:500L
3.reliable and balance rotation
Hot Sell Super Quality Gearbox Concrete Mixer
Descriptions of Gearbox Concrete Mixer:
Gearbox concrete mixer is a gravity type of double-conic reversing drum concrete mixer, the drum transit by gear, the drum rotates clockwise during mixing and anti-clockwise during discharging. It is portable and movable. The mixer can mix plasticity and damp half-dry concrete. These mixer services for ordinary construction site, roads, bridge projects and precast plant.
Technical Specifications of Gearbox Concrete Mixer:
Model: JZC500
Delivery capacity: 500L
Through-put capacity: 800L
Productivity: 18-20m3/h
Mixing and lifting power: 18.5kw
Water pump power: 5.5kw
Accuracy of water supply Error: 2%
Drum rotating speed: 13r/min
Max aggregate size: 60mm
Overall weight: 2400kg
Overall dimensional(L*W * H)In delivery condition: 3500*2200*3200mm
Advantages of our gearbox concrete mixer:
1)rich export experience, large factory
2)have CE and ISO certification
3)compact structure, smooth running.
4) competitive price and best service
5) reliable and balance rotation.
6) low noise and energy consumption
JZC gearbox concrete mixer includes JZC250, 350, 500.
Model | JZC250 | JZC350 | JZC500 |
Discharge volume | 250L | 350L | 500L |
Charging volume | 320L | 560L | 800L |
Capacity | 6~8 m3/h | 10~14 m3/h | 18~20 m3/h |
Rotating speed | 17 r/min | 14 r/min | 13 r/min |
Mixing motor | 4kw | 5.5kw | 7.5kw |
Hoisting motor | 4KW | 4.5KW | 5.5kw |
Pump motor | 0.55kw | 0.55kw | 0.55kw |
Weight | 1500kg | 1950kg | 2400kg |
Dimensions (L x W x H) | 2260x1990x2750 mm | 2766x2140x3000 mm | 3500x2200x3200 mm |
