Home > Products > thickening equipment > Factory Price Mining Thickener For Processing Plant , Thickener Machine Cost
Factory Price Mining Thickener For Processing Plant , Thickener Machine Cost
- 30 Set / Sets per Month
- Qingdao China
- T/T
You May Like
-
China Factory Price Mining Thickener Tank Cost for Zinc Processing Plant
-
China Factory Price Mining Thickener Tank for Gold Tailing Line
-
China Factory Price Gold Tailing Machine Thickener Tank
-
China Factory Price Copper Separator Mining Thickener Cost
-
NT Mining Thickener Equipment With Peripheral Rack Transmission
-
(ISO 9001& CE) China Factory Price Mining Thickener Tank For Gold Processing Plant
Product Details
| Condition | New | Application | Mining | |
| Motor Type | AC Motor | Power(W) | 1.1kw-7.5kw | |
| Production Capacity | 5-1400 t/d | Place of Origin | Shandong, China | |
| Brand Name | Xinhai | Model Number | NZSG | |
| Dimension(L*W*H) | depend on the model | Certification | ISO 9001, CE | |
| Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Thickener —Product Feature
1.Deaeration cell is provided to prevent solid particles from attaching to bubbles so that solid particles can fall like a parachute.
2.The mineral-feeding pipe is lower than the pulp surface; it prevents the air to be brought in while feeding
3.The feeding sleeve is moved to a lower position and receiving plate is equipped. Therefore, the fed slurry fall evenly and steadily, preventing rolling phenomena because of the residual pressure from feeding
4.Inner overflow weir is equipped to make the pulp flow on pre-designed route, avoiding short circuit, enlarging the sedimental area
5.Inner overflow weir is made into indented shape, eliminating part suction phenomena induced by unleveled overflow weir.
6.The peg linear is changed from oblique lines to curves. So the discharging underflow has higher density, and treatment capacity is enhanced.
Thickener — Product Application
It is widely used for dealing with slime, wastewater, waste residue in metallurgy, mine, coal, petrochemical industry, building materials, environmental protection department etc.
Thickener — Product Principle
This thickener consists of round thickener and harrow scrapping machine, the solid particles suspend in thickener settling by gravity, the pulp in the upper turn into clean water, so that the separation can be realized. Slime that sediment in the bottom of the thickener is discharged by the harrow scrapping continuously, and clean overflow from the upside.
Thickener — Technical Parameter
Model | D of the tank | Depth of the tank | Sedimental area | capacity | Motor model | Motor power |
NZSG-2.5 | 2500 | 1850 | 4.9 | 5-10.8 | Y90L-6 | 1.1 |
NZSG-3A | 3000 | 1800 | 7 | 5-23.3 | Y100L-6 | 1.5 |
NZSG-3 | 3600 | 10.2 | 5-28.5 | |||
NZSG-5 | 5000 | 2956 | 16 | 16-90 | Y90L-4 | |
NZSG-6 | 6000 | 28.3 | 98 | |||
NZSG-7 | 7000 | 3000 | 38.5 | 140 | Y112M-6 | 2.2 |
NZSG-8 | 8000 | 3318 | 50.2 | 185 | Y132S-6 | 3 |
NZSG-9 | 9000 | 3376 | 63 | 210 | ||
NZSG-12 | 12000 | 3600 | 113 | 370 | ||
NZSG-15 | 15000 | 4000 | 176 | 580 | Y132(M2)-6 | 5.5 |
NZSG-18 | 18000 | 4400 | 255 | 960 | YCT200-413 | 7.5 |
NZSG-20 | 20000 | 4400 | 315 | 1400 | Y160(M2)-8 |
Group Introduction
Xinhai Group founded in 1993 has grown into the industry group involving mineral processing, wearable rubber, mining investment and LFC Machinery after twenty years development. We have been always committed to providing customers with professional, perfect, efficient equipment and solutions. The whole solution we provide for you with the core of reliable & efficient mineral processing schemes and environmental-protection & energy-saving tailings dry stacking, makes us stand up in every EPC bid.
