2014 Best Seller Hardwood Charcoal Carbonization Stove

Specifications

2014 Best Seller  Hardwood Charcoal Carbonization Stove

we can carbonize peanut shell ,branch

,corncob,sawdust ,wood log,wood residue,coconut shell etc.

Character

 High carbon content and Green-Tec smokless  hardwood charcoal carbonization stove is ideal equipment for mass charcoal production. This type of smokeless carbonization stove adopts the structure of unique air storage chamber, to fully reuse the smoke produced during the process of carbonization. 60% of the redundant smoke can be used in drying and carbonization which saves energy and increases the enterprise revenue.

1

There are 4 steel drums at the top of the machine body. Under each drum, it’s a small room to make fire.

2

The 4 drums have lids on top, and in the middle of the lids, there also connect with 4 pipes, is used for gases to escape (gases will come out when heating the drum). This pipe is called the "retort." Fill the retort with the chunks of hard wood and place the lid on top.

3

Place wood and start the fire at the bottom of the drums. Place the retort inside the drum, resting it on the fire.

4

Wait for the fire to get really hot.

5

 It should be burning for about three hours and the smoke have been released, which means that the water, tar and other compounds in the hardwood chunks are being released. Keep the temperature up by occasionally adding wood to fire.

6

Watch for the smoke, which means the gases have been burned out. Pull the rods out to drop the retort into the burned wood and ashes, stopping the flow of air to the charcoal inside.

7

Wait an hour, then lift the retort out of the drums. Wear welder's gloves, as the retort may not be cool enough to handle. Place the retort in dirt and make  it to cool further.

8

After about two more hours, check to see if the retort is cool enough to touch. If so, remove the lid to check the results of your burn. If successful, the hardwood chunks inside should have reduced by about a third, and been converted to lump charcoal.

Certification of Our Factory and Products

Gongyi Lantian Machanical Plant has 28 years experience for Briquetting and Pelletizing solution. Sincerely hope to be your business partner.
