Gas Flow Typ Furnace to Carbonize Coconut Shell Charcoal

Specifications

gas flow typ furnace to carbonize coconut shell charcoal

Raw material application  :

we can carbonize peanut shell ,brance ,corncob,sawdust ,wood log,wood residue,coconut shell etc.

Character

Gas flow typ furnace to carbonize coconut shell charcoal is ideal equipment to for mass charcoal production. This type of smokeless carbonization stove adopts the structure of unique air storage chamber, to fully reuse the smoke produced during the process of carbonization. 60% of the redundant smoke can be used in drying and carbonization which saves energy and increases the enterprise revenue.

1.There have 4 of steel drums at the top of the machine body. Under each drum, it’s a small room to make fire.

2.The 4 drum have lids on top, and in the middle of the lids, there also connect with 4 pipes, is used for gases to escape (gases will come out when heating the drum). This pipe is called the "retort." Fill the retort with the chunks of hard wood and place the lid on top.

3.Place wood and start the fire at the bottom of the drums. Place the retort inside the drum, resting it on the fire.

4.Wait for the fire to get really hot

5.Keep an eye on the smoke. You should be burning for about three hours and the smoke should be……, which means that the water, tar and other compounds in the hardwood chunks are being released. Keep the temperature up by occasionally adding wood to fire.

6.Watch for the smoke ……, which means the gases have been burned out. Pull the rods out to drop the retort into the burned wood and ashes, stopping the flow of air to the charcoal inside.

7.Wait an hour, then lift the retort out of the drums. Wear welder's gloves, as the retort may not be cool enough to handle. Place the retort in dirt and allow it to cool further.

8.After about two more hours, check to see if the retort is cool enough to touch. If so, remove the lid to check the results of your burn. If successful, the hardwood chunks inside should have reduced by about a third, and been converted to lump charcoal.

Certification of Our Factory and Products

As a 28 years experience for Briquetting and Pelletizing

company.we have gained the world-wide clients :

After sales service:

In the after sales service, Lantian machinery has a team of briquetting professionals ready to help you. We provide one year warranty for all of our products and six month for the wear parts. Spare and wear parts are always close to you.
