Home > Products > All Kinds of Lathe > X6323A Universal Radial Milling Machine,radial Milling Machine
X6323A Universal Radial Milling Machine,radial Milling Machine
US$ 5,000 - 15,000
/ Set
1 Set(Min. Order)
- Qingdao Port or Shanghai Port
You May Like
-
Cylindrical Grinding Machine M13 Series,grinding Machine, Cylindrical Grinding Machine
-
CK6130 CNC Lathe Machine, CNC Lathe Machine, Lathe
-
Z3040*13 RADIAL DRILLING MACHINE,drilling Machine,radial Drilling Machine
-
M618A Surface Grinding Machine,sureface Grinding Machine, Grinding Machine
-
Z3040*10 Radial Drilling Machine,driling Machine, Driller
-
X6336 Turret Milling Machine,milling Machine,Horizontal Milling Machine
Product Details
| Condition | New | Place of Origin | Liaoning, China | |
| Brand Name | Acecare | Model Number | X6323A | |
| Type | Universal | CNC or Not | Normal | |
| Dimension(L*W*H) | 1400*1476*2030mm | Weight | About 1100KG |
Product Description
X6323A Universal Radial Milling Machine
| Unit:mm | ||||
| Item/Mode | X6323a | |||
| Table size | 230*1067(9"*42") 230*1246(9"*49") | |||
| Long Travel | 650 840 | |||
| Cross Travel | 305 | |||
| Vertical Travel | 400 | |||
| T-slot No.and size | 3*16 | |||
| Ram Travel | 312 | |||
| Distance From Spindle Nose To Table Surface | 15~415 | |||
| Spindle Hole Taper | (standard):R8 (optional):ISO30/ISO40 | |||
| Spindle Travel | 127 | |||
| Spindle Speed | (standard):(shiftgrade)50HZ65-4500 60HZ:80-5440 | |||
| (optional):(variable)65-4500 | ||||
| Auto.quill feed | (three steps):0.04(0.0015")/0.08(0.003")/0.15(0.006")mm/revolution | |||
| Spindle Motor | 2.25KW/3HP | |||
| Head Swivel | 90º | |||
| Head Tilting | 45º | |||
| Dimension Of Package | One Miller Per Case | 1400*1476*2030 | ||
| Two Miller Per Case | 1450*1570*2080 | |||
| Three Miller Per Case | 1450*2180*2080 | |||
| G.W/Set | 1100 | |||
