HOT SELLING !smart Card Reader Usb Acr38
- sheznhen/hk
- T/T L/C D/P D/A Money Gram Credit Card PayPal
You May Like
Product Details
| Brand Name | hkshanhai | Model Number | Acr38 | |
| Type | SD Card, XD Card, MMC Card, Memory Stick Card, SM Card, CF Card | Interface | USB | |
| Card Slots | All in 1 / Multi in 1 | Installation | Internal | |
| Place of Origin | Guangdong, China |
Product Description
Specifications
smart card reader usb acr381. Internal Smart Card Reader Writer
2. USB2.0 Interface
3. FCC/CE/ROHS approved
smart card reader usb acr38
Introduction:
The CCID smart card reader/writer is a USB full speed device, which is the interface for the communication between a computer and a smart card. It is designed for PC environment, ultimate smart card peripheral for a PC.
CCID reader is intended to be compatible with .NET Windows platforms being developed by Microsoft Corporation.
CCID is a key partner of PC as a smart card is widely a main component in network security and electronic payment system. Providing secured network computing environment by its data encryption function, the SDK package allows users to easily develop their own application to best meet the specific system needs.
Features:
- USB full speed interface to PC with simple command structure
- Read and write all microprocessor cards with T=0 or T=1 protocols
- Supports SLE 4418/28/32/42 memory cards
- Supports most common memory-based smart cards, including I2C bus protocol cards (from 1k bits up to
1024k bits) and secure memory cards (Atmel AT88SC153 and AT88SC1608)
- Support 1.8V. 3V and 5V MCU cards
- Short Circuit Protection
- Certificate of conformance: ISO 7816-1/2/3, PC/SC, CE, FCC, Microsoft WHQL, EMV certified
- ISO7816-1/2/3 compatible smart card interface
- Support PPS (Protocol and Parameters Selection) with 1743 - 305200 bps in reading and writing smart cards
- 768 bytes RAM size and 16K bytes ROM size
Typical Applications:
- Home Banking and Home Shopping
- Electronic Commerce
- Checking the balance of account of re-loading an electronic purses
- Network access control
- S/W locking
- Digital signature
- Loyalty and promotions
- Stored value
- Identification
- Ticketing
- Parking and toll collection
Technical Specification:
Universal Serial Bus Interface
- Type..................................USB v2.0 full speed, four lines: +5V, GND, D+ and D-
- Power source......................From USB
Smart Card Interface
- Standard............................. ISO 7816 1/2/3, T=0 and T=1
- Supply current..................... max. 50mA
- Smart card read / write..........speed 1743 - 305200 bps
- Short circuit protection........... +5V / GND on all pins
The presence of the smart card power supply voltage is indicated through a green LED on the reader
- CLK frequency........................ 4 MHz
- Card connector .......................Contact
- Card insertion cycles................min. 100,000
Case
- Dimensions..............................97mm (L) x 72mm (B) x 18.5mm (H)
- Color.......................................Golden
Operating Conditions
- Temperature............................. 0 - 50° C
- Humidity.................................. 40% - 80%
Standard/Certifications
- EMV Level 1, ISO7816-1/2/3, PC/SC, CE, FCC, Microsoft WHQL 98, ME, 2K, XP
OS
- Windows 98, ME, 2K, XP, .NET
OEM
- OEM-Logo possible, customer-specific colors, casing, and card connector
....
