High Temperature Pressure Sensor

FOB Price

Negotiable / Perch

100 Perches(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin

Guangdong, China

$keywords$
1.Various output scheme:2.0/2.5/3.3mV/V ;4 ~ 20mA, 0 ~ 5/10Vdc
2.OEM accep

$keywords$

Model:QPT-102

Range:0~10 bar...2000 bar

Feature:

1. Accuracy : 0.5% FS, 1.0% FS

2. Various output scheme:2.0/2.5/3.3mV/V ;4 ~ 20mA, 0 ~ 5/10Vdc.

3. Externally adjust zero and full scale.

4. 80% self-calibration with external.

Technical Specifications

Measuring range	bar	0/10,0/20,0/35,0/50,0/70,0/100,0/200, 0/350,0/500,0/700,0/1000,0/1400,0/2000
Overload pressure	%FS	150(ure: 2100 bar )
Signal output @ FS	mV/V	2.0, 2.5, 3.3(selectable)
Signal output @ FS	amplified output signal	4~20mA, 0~5V, 0~10V(selectable)
Power supply	mV signal	8~12Vdc
Power supply	amplified signal	12~36Vdc(Model 24Vdc)
Combined error	%FS	0.3,0.5(standard),1.0 (selectable)
Zero adjustment	%FS	±10
Span adjustment	%FS	±6
Repeatability	%FS	0.2
Output resistance	Ω	350±10%
Insulation resistance	M Ω	≥500 @ 100 Vdc
Max.temp.@ wetted parts	°C	400
TCZ	%FSO/10°C	0.5
TCS	%FSO/10°C	0.5
Long-term stability	%FSO/year	<0.15
Compensated temp.	°C	0~80
Pressure connection	external thread	1/2"-20 UNF-2A(standard),M14×1.5,M18×1.5
Electrical connection	connector	6-pin (standard) male tighten connector, 8-pin male screw in connector
Max.mounting torque	N.m.	40

Ordering code: model- range-rated output-accuracy-pressure connection-electrical connection-electrical connection-the other requests.

Example: QPT-102-0/200bar-4/20mA-0.5%FS-M14x1.5-6-pin-***

Dimensions:(unit:mm)

Electrical connection:
