ZL15F 1.5T Mini Loader
- Qingdao
- T/T
You May Like
Product Details
| Condition | New | Brand Name | HY | |
| Model Number | ZL-15F | Place of Origin | Shandong, China | |
| Type | Mini Loader | Moving Type | Wheel Loader | |
| Dimension(Long * Breadth * High) | LxWxH | Rated Load | 1500KG |
Product Description
Specifications
mini loadermini loader
ZL15F EURO III emissionsmini loader | |
Model | ZL15F mini loader |
Rated loading weight | 1500kg |
Rated bucket capacity | 0.8CBM |
Bucket width | 1800mm |
Track base | 1480mm |
Wheel base | 2005mm |
Min. swerve diameter | 4500mm |
Min. ground clearance | 260mm |
Dump height fully raised | 2600mm |
Reach fully raised | 1070mm |
Lifting time | 4s |
Hydraulic cycle time | 8s |
Max. tilt angle | 30% |
Max. bucket breakout force, lift cylinder | 36KN |
Driving mode | Four-wheel drive |
Operating weight | 3600kg |
Dimension(L×W×H) | 4800*1770*2720mm |
Engine model | 498(EURO III emissions) |
Engine type | In-line arrangement,water cooled,four-cycle diesel engine |
Engine starting mode | Electric |
Rated speeds | 2400rpm |
Rated power | 36.8kw |
Brake mode | Four-wheel hydraulic spread-shoed brake |
Color | According to the requirements of customers |
Packaging details | Nude package,3Units/40’s HC |
Delivery time | 25 days after confirm the order |
We can supply many types of mini loader.
Each type of mini loader has good quality low mini loader price and quick efficiency.
Welcome to inquire us.
