Professional 2KW VHF/UHF Transmitter

Specifications

Professional 2KW VHF/UHF Transmitter

VHF/UHF TV transmitter Professional designed and manufactured,high reliability and low price.VHF&UHF.300W/500W/1KW/2KW.1-meter 19'-rack.

Product Display :

Technical Specifications :

Overall performances:

1. Working frequency:                  VHF/UHF

2. Output power:                          2KW

3. Output impedance:                    50Ω

4. VSWR of output load impedance:≤1.12

5. Inter-modulation distortion:        ≤-50dB

6. Useless transmission:                In adjacent channel≤-40dB

                                                    Out adjacent channel≤-60dB

7. RF output interface:                  Φ40

8. Power supply:                          Single-phase 220V

9. Shape size:                              1475mm×960mm×675mm

10.Weight:                                  220KG

Image performance:

1. Video frequency input level:          1VP-P positive polarity

2. Video frequency input impedance:  75Ω

3. DG:                                          ±5%

4. DP:                                           ±5°

5. Luminance nonlinear:                   ≤10%

6. Group delay:                               ≤±60ns

7. Signal-to-clutter ration of low frequency period interference:  ≥50dB

Sound performance:

1. Audio input level:                            0dBm±6dB

2. Audio input impedance:                    10KΩ (imbalance)

                                                          600Ω (Balance)

3. Maximum frequency deviation:              ±50KHz

4. Harmonic distortion:                           ≤1%

5. The amplitude frequency characteristics:±1dB

6. Signal-to -clutter:                              ≥60dB
