High Quality Paper Core Recutting Machine ;paper Tube Forming Machine
Negotiable
/ Set
1 Set(Min. Order)
- tianjin
You May Like
-
Paper Tube Curling Machine With High Quality
-
UNI-4250 Paper Tube Machine With 4 Heads High Quality
-
Paper Tube Forming Making Machine Wih High Speed
-
UNI-150B Paper Tube Curling Machine With High Quality
-
High Speed Hydraulic Paper Slitting Machine With Good Qualiy
-
Spiral Paper Tube Core Making Formine Machine for Small Tube
Product Details
| Condition | New | Product Type | Paper Core Machine | |
| Processing Type | Cutting Machine | Place of Origin | Hebei, China | |
| Brand Name | unipand | Model Number | UNI-1500B | |
| Voltage | 380V,3phase,4wire | Power(W) | 2.2KW | |
| Dimension(L*W*H) | 4400*700*1200 | Weight | 1300kg | |
| Certification | CE | Warranty | 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
UNI-1500B Auto Precision Paper Core Cutter1.Tube Length:50-1500mm
2.Tube Diameter: 50-125mm
3.Cutting Tolerance:0.01mm
CT-1500B Auto Precision Paper Core Cutter Main Specification and Equipment:
Parameter
| tube length | 60-1500mm | tube diameter | 50-125mm |
| blade quantity | 10set | cutting way | tube rotate with blade axes |
| loading/unloading way | auto | operator | 1 |
| way of moving knife | pneumatic | power input | 380V,3phase,4wire |
| cutting thickness | 3-18mm | cutting tolerance | 0.01mm |
Control System
| PLC aontroller | Delta,Taiwan | man-machine interface | text |
| edition of program | JS-A5 | driving components | CHNT |
| signal components | Omron | pneumatic components | AIRTAC |
Size (mm)
| mainframe(L*W*H) | 4400*700*1200 | total weight | 1300kg |
| power of mainframe | 2.2KW | power of auxiliary machine | 1.5KW |
| rotate speed of main-spindle | 500r/min |
