11~750KV Composite Insulator
US$ 10 - 50
/ Piece
500 Pieces(Min. Order)
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Hubei, China | Brand Name | TONLY | |
| Type | Insulator | Material | Composite Polymer | |
| Application | High Voltage | Rated Voltage | 11~750KV |
Product Description
Specifications
KEMA Test Reports covering 11/24/33/36/66/230/400/500/750KV post & suspention composite insulators for electrical railway.| Catenary composite insulator | ||||||||||||
| Type | Rated | Specified | Length | Minimum | Minimum | Lighting | Dry | Wet | Weight | |||
| Voltage | mechanical | H,mm | arcing | nominal | impulse | power | power | kg | ||||
| kV | bending | distance | creepage | withstand | frequency | frequency | ||||||
| load | h,mm | distance | voltage | voltage | voltage | |||||||
| kN | L,mm | more | >= | >= | ||||||||
| than | ||||||||||||
| RQX-25/120-HH-1 | 25 | 120 | 830+/-5 | 600 | 1200 | 360 | 210 | 180 | 2.7 | |||
| RQX-25/120-HH-2 | 25 | 120 | 880+/-5 | 650 | 1500 | 420 | 250 | 220 | 3.2 | |||
| RQX-25/120-HT-1 | 25 | 120 | 750+/-5 | 525 | 1200 | 330 | 220 | 170 | 2.5 | |||
| RQX-25/120-HT-2 | 25 | 120 | 785+/-5 | 560 | 1300 | 360 | 210 | 180 | 3 | |||
| RQX-25/70-HH-1 | 25 | 70 | 730+/-5 | 490 | 1200 | 330 | 195 | 165 | 2.7 | |||
| RQX-25/70-HH-2 | 25 | 70 | 910+/-5 | 670 | 1600 | 420 | 250 | 220 | 3.2 | |||
