F5J2B 5L Jacketed Glass Reactor - Lab Equipment

FOB Price

US$ 1,800 - 2,000 / Unit

1 Unit(Min. Order)

Port Shanghai

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shanghai, China	Brand Name	SENCO
Model Number	F5J2B	Voltage	220V
Dimension(LWH)	6045110H (cm)	Weight	31 Kg
Certification	CE	Warranty	13 Month
Type	Other, Jacketed Reactor, Integrated Type

Product Description

Specifications

F5J2B Jacketed Reactor
-Working Temp: -70C~200C;
- 5+1 necks integrative reaction flask
- Tangent Circulation

F5J2B -Jacketed Reactor

Apply with SENCO unique integrative jacket reaction flask.

Advantage--Good vacuum performance, easy assembly & maintenance, few wearing parts.
Standard--Stirring, Reflux Condensing, Charging, and Temperature Measuring function;

Optional--Distillation,Dripping,Auto CW/CCW stir, Liquid Separation, Sampling bottle etc

		Standard Model	F5J2B
	0	Relevant Model	F5J2A
Parameters	1	Reaction Flask (L) (Integrated Style)	5L, Bottom Discharge
	2	Neck No. of Reaction Flask	5+1
	3	Rotation Speed (rpm)	40-720
	4	Torque (Ncm)	80
	5	Power	220V
	6	Dimensions (cm)	60X45X110H
Configurations	7	Frequency Conversion Speed Control	•
	8	Digital Display	Rotation Speed
	9	PTFE Seal Assembly	•
	11	PTFE Flush Type Discharge Valve	•
	12	PTFE Suck Type Discharge Valve	/
	13	Charging Valve	•
	14	Temp. Measure Neck	•
	15	Vacuum Meter	/
	16	Auto CW/CCW Stir *	/
	17	Multi-functional Wide Neck (F120)	/
	18	3-hole Wide Neck Cap	/
	19	Wide Neck Cap Holder	/
	20	Reflux Condensing	•
	21	Distillation-Receiving *	Ο
	22	Liquid Separation *	/
	23	Rectification-Receiving *	/
	24	Drip System (5L)	/
	25	Drip Set	0.25L
	26	Tangent Style Jacket inlet/outlet	•
	27	Sampling Bottle	Ο
	28	Lockable Wheels *	/
Safety Features	29	Over-current Protection	•
	30	No-spark Electronic Control System	•
	32	Metal Shield	/

Symbol Instruction: / - None,• - Equipped,Ο - Optional ( * - Only available when ordering of product, not for separate sale)

Note: Some specifications of relevant models may have differences from that of standard model. Details available at request.
