Home > Products > JACKETED REACTOR 10L-100L > FC10003 100L Cap Style Jacketed Glass Reactor-SENCO- Complete Flange joints
FC10003 100L Cap Style Jacketed Glass Reactor-SENCO- Complete Flange joints
USD $15,000 - $17,800
/ Unit
1 Unit(Min.Order)
- 5 Unit / Units per Month
- Shanghai
- T/T L/C D/P D/A Credit Card
You May Like
-
FC1003 10L 2-Piece Jacketed Glass Reactor-SENCO- Complete Flange joint
-
FC5003 50L Cap Style Jacketed Glass Reactor-SENCO- Complete Flange joints
-
5L SENCO Multifunctional Reactor F5HA, China made
-
F2HA, 2L SENCO Multifunctional Reactor
-
1-5L SENCO Multifunctional Reactor-- Bath Temp: RM~180C
-
Up Discharge Pilot Multifunctional Reactor-SENCO
Product Details
| Condition | New | Automatic Grade | Semi-Automatic | |
| Type | Reaction Kettle | Place of Origin | Shanghai, China | |
| Brand Name | SENCO | Model Number | FC10003 | |
| Voltage | 220V | Power(W) | 200 W | |
| Dimension(L*W*H) | 120*70*250H (cm) | Weight | 250 Kg | |
| Certification | CE & ISO | Warranty | 13 Month | |
| After-sales Service Provided | Overseas third-party support available |
Product Description
Specifications
100L 2-piece Jacketed Reactor- Work Temp: -70C~200C
- Vaccum <399pa
- Tangent jacket circulation w/adaptor
-Bottom Discharg
FC10003 - SENCO 2-piece Cap Style Chemical Jacketed Reactor
Capacity: 100L
Temp. Range: -70 °C ~200 °C
Necks: 7 + 1
stirring, condensing, charging, dripping, solid charging,thermometer,extra neck for spare +discharging
Jackete: 2-piece reaction flask with inlet / outlet
Heating/Cooling: Offer Tangent Circulation inlet/outlet with adaptor;
Vacuum Rate: <399pa
Operation Temperature: -70C~200C
Function included:
Vacuum Rate: <399pa
Operation Temperature: -70C~200C
Function included:
- Standard: Stirring, Reflux Condensing, Charging, Temp. Measuring, Dripping and Solid feed openning;
- Optional: Distillation, Rectification, Separation, Sampling, etc.;
- Optional: Distillation, Rectification, Separation, Sampling, etc.;
Features:
- Reaction flask equips SENCO no-dead angle PTFE discharging valve (Flush type or Suck type optional). All reactant is able to join reaction process with no pollution.
- Reaction flask equips SENCO no-dead angle PTFE discharging valve (Flush type or Suck type optional). All reactant is able to join reaction process with no pollution.
- Equips Tangent Jacket Circulation, which achieves quicker heat exchange performance.
- Frequency Conversion Stirring System, which offer longer life service, stabler operation, and sufficient stiring effects.
- More shapes of stirring agitators are available according to nature of target reactants.
- Easy clip Flange clamp, makes all flangejoint connects simple and safe.
FC10003
Neck Figure
Big cap and PTFE Charge Valve
Ex-Proof is Optional choice
Ex Level: ExdIIBT4
Packing
* Engineering team presided over by professor level chief engineer who has over 30 years practical working experience, Products inherit characters of Safe, Durable and Efficient.
Why choose Senco
*Factory occupies 2300m2 land, is able to guarantee pure Senco quality and fast delivery. Genuine products assured from factory direct sale.
SENCO is a reputed top brand among Chinese Suppliers for Rotary Evaporators and Reactors. She is professional in D&E, Manufacturing and Oversea Customer Support.
It is a technology oriented company with professor and engineering team who have developed quite some patented unique technologies and designs which make SENCO products featured in Safe, Durable and Efficient.
Hope you will have chance to try our services, products, to work with our people. A different experience--Simple & Relexed
