LM2596HVS LM2596HV DC-DC Adjustable Step Down Buck Converter Power Module 4.5-50V to 3-35V

FOB Price

USD $0.89 - $1.03 / Piece

1 Piece(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	LM2596HVS
Model Number	LM2596HVS

Discription

the volume of L 40 * W 21.5 * H 13.5mm (including potentiometers).
Input: IN+ input positive IN- input negative
Output: OUT+ output positive OUT- output negative
Adjustment method: first correct input power (between 4.5-60V) then multimeter to monitor the output voltage and adjust potentiometer (usually clockwise turn boost, buck turn counterclockwise),
Output voltage: (3-35V) continuously adjustable (recommended load debugging).
Minimum pressure: 1.5V
Output current: rated current 2A, 3A maximum
Output Power: 15W maximum
Conversion efficiency: up to 92% (output voltage, the higher the efficiency)
Static power consumption is only about 6mA.
Connection: Welding, plus pin can be directly soldered after the PCB.
Operating temperature: Industrial grade (-40 to + 85 degrees Celsius)
Load regulation: ± 1%
Voltage Regulation: ± 0.5% (mean time to achieve no-load output voltage will be higher, but as long as there is with 1MA load, the output voltage will be normal, does not affect the functionality, ease of use.)
Short circuit protection: current limiting, thermal protection, self-recovery.
