Semi-automatic Blow Moulding Machine
- 1 Set / Sets per Month
- shanghai port for semi-automatic blow moulding machine
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | HuangYu | |
| Model Number | HY-B-1 |
Product Description
Specifications
semi-automatic blow moulding machine1)Germany FESTO components
2)BOTHFIT PLC
3)CE certificate
4)for 50ml-6L bottle
semi-automatic blow moulding machine
The features of the machine
1). The machine adopts revolving infrared pre-heat system, it ensures pet performs
be heated evenly.
2). The machine uses mechanical-double-arm mould clamping system which ensures the mould
be closed tightly even under high pressure and high temperature.
3).The air system has been divided into two parts: Pneumatic action part and bottle
blow part to meet the different pressure requirements for the action and blow, it
can provide sufficient and steady high pressure for blowing large irregular shaped
bottles
4).Wide -mouth and hot-filling bottles can also be made.
Main technical parameter
sort | item | unit | Technical data | |
HY-B-1 |
| |||
Blowing machine | capacity | L | 2(2-cavity) 3(1-cavity) |
|
Theory capacity | pcs/h | 450-1000 |
| |
bottle caliber | mm | 15-75 |
| |
Mouding board size | mm | 350*450 |
| |
Allowable thicfness | mm | 120-280 |
| |
Movinr distance | mm | 150 |
| |
Working air pressure | Mpa | <=1.0 |
| |
Blowing air pressure | Mpa | <=4.0 |
| |
Blowing power | KW | 0.2 |
| |
weight | Kg | 800 |
| |
size | mm | 1360*600*1580 |
| |
oven | power | KW | 10 |
|
weight | Kg | 450 |
| |
size | mm | 1450*700*1150 |
| |
mould finished products
