5 Gallon Bucket Filling Line/Plant/Equipment
- shanghai pot
- T/T Credit Card
You May Like
Product Details
| Condition | New | Application | Food, Beverage | |
| Packaging Type | Bottles, Barrel | Packaging Material | Wood | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | 380v/50hz | Power | 6KW | |
| Place of Origin | Jiangsu, China | Brand Name | Huanyu | |
| Model Number | QGF-450 | Dimension(L*W*H) | 6000*3000*2000mm | |
| Weight | 2000kg | Certification | CE/SGS | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1.5 Gallon Bucket Filling Line/Plant/Equipment2. Linear and rotary type Filling
3.3/5 gallon Filling
4.100-2000bph
5 Gallon Bucket Filling Line/Plant/Equipment
1) Summry:
QGF series 5 gallon filling machine is designed for producing 5 gallon barrel drinking water. There are 8 kinds of machines which can produce 60, 100, 150, 300, 450, 900, 1200 and 2000 5 gallon barrel drinking water per hour. Every machine is consisted of rinser, filler and capper. The rinser has several sprays which can be used as for both clean water rinsing and disinfectant rinsing. The disinfectant can be recycled. The machine also has automatic capping device, and cap rinsing device. The whole production line can automatic feeding barrel, rinsing, sterilizing, filling, capping, counting and output.
2) 5 Gallon Bucket Filling Line/Plant/Equipment Technique Parameter
QGF 60 | QGF 100 | QGF 150 | QGF 300 | QGF 450 | QGF 600 | QGF 900 | QGF 1200 | QGF 2000 | |
Filling volume (L) | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 |
Bottle specification (mm) | 270*490 | 270*490 | 270*490 | 270*490 | 270*490 | 270*490 | 270*490 | 270*490 | 270*490 |
Capacity | 60 | 100 | 150 | 300 | 450 | 600 | 900 | 1200 | 2000 |
Air pressure (MPa) | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 |
Air consumption (L/min) | 200 | 300 | 300 | 400 | 500 | 500 | 800 | 1200 | 1200 |
Power (kW) | 1.4 | 2.12 | 3.77 | 6.5 | 7.5 | 7.5 | 10 | 14 | 15 |
Rated voltage (V) | 380 | 380 | 380 | 380 | 380 | 380 | 380 | 380 | 380 |
Dimensions (L*W*H) (mm) | 2470*800*1580 | 3485*700*1550 | 4685*1420*1700 | 5130*2500*2220 | 6600*3500*2170 | 6600*3500*2170 | 6600*5000*2170 | 2800*2400*2700 | 2900*3500*2700 |
Weight (kg) | 800 | 800 | 1000 | 1750 | 2200 | 2500 | 2800 | 3100 | 4000 |
5 Gallon Bucket Filling Line/Plant/Equipment Picture:
ZhangJiaGang Huanyu Beverage Machinery Co.,Ltd is a professional Manufacturer of Beverage Filling Machine in China. In addition to 5 gallon filling machine, we also produce:Small bottle water filling machine,Juice/Tea drink filling machine,Carbonated drinks/Beer Filling machine,Pop can Filling machine,water treatment equipment, blow molding machine, Bottle Unscrambler ,shrink labeling/packing machine and so on.
More detailed information .Please feel free to contact us.
Name | Derek Liang |
Mobile phone | +86-15962348757 |
Office Tel | +86-0512-58536922 |
Skype | derekmachinery |
522756388 |
