Full Automatic 20L Barrel Water Filling Machine
- shanghai port
- T/T
You May Like
-
Automatic Beer Filling Machine
-
Beer Washing Filling Capping Machine Monoblock
-
Beer Filling Capping 2-In-1 Machine,beer Filling Machine,
-
Beer Filling Machine,beer Machinery,beer Filling Line
-
Beer Filling Machine
-
Beer Filling Capping 2-In-1 Machine,beer Filling Machine,beer Machinery,beer Filling Line
Product Details
| Condition | New | Application | Food, Beverage | |
| Packaging Type | Barrel | Packaging Material | Plastic | |
| Automatic Grade | Automatic | Driven Type | Pneumatic | |
| Voltage | 380v/50HZ | Power | 3.8KW | |
| Place of Origin | Jiangsu, China | Brand Name | HY | |
| Model Number | QGF-1000 | Weight | 1500KG | |
| Certification | CE | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1.water filling machine2.bottle:3-5 gallon
duct:pure water&drinking water
4.capacity:100-3000bph
water filling machine
Descriptions:
(1) This filling line specially produces 3&5 gallons barreled drinking water.
(2)This series barreled filling production line integrates bottle washer, filler and sealer into one unit.
(3) In order to achieve the purpose of washing and sterilizing, bottle washer adopts multiple liquid injections washing and disinfectant spray, and washing solution can be used circularly. The sealer can seal bottle caps automatically.
(4) This filling line equips with water spraying device to sterilize caps of bottles in order to ensure those caps are aseptic and healthy.
(5) This line also can automatically carry out bottle washing, sterilizing, filling, capping, counting and products discharging.
(6) It has features of complete functional, novel design, and high degree of automation. It is a new kind of barreled water auto-producing line, which integrates mechanism, electricity and pneumatics technologies together.
technology parameter
Model | QGF-100 | QGF-300 | QGF-450 | QGF-600 | QGF-900 | QGF-1200 | QGF-2000 |
Number of filling heads | 1 | 2 | 3 | 4 | 6 | 12 | 16 |
Filling capacity | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 |
Barrel size (mm) | φ270×490 | φ270×490 | φ270×490 | φ270×490 | φ270×490 | φ270×490 | φ270×490 |
Production capacity (b/n) | 100-120 | 200-240 | 300-400 | 600 | 900 | 1200 | 2000 |
Gas pressure (Mpa) | 0.4-0.6 | 0.4-0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 |
Gas consumption (m3/min) | 0.37 | 0.6 | 0.6 | 1.2 | 2.2 | 3 | 4.5 |
Motor power(kw) | 1.75 | 3.22 | 4.8 | 8.5 | 8.5 | 8.5 | 8.5 |
Rated voltage (V) | 380V/50Hz | 380V/50Hz | 380V/50Hz | 380V/50Hz | 380V/50Hz | 380V/50Hz | 380V/50Hz |
Overall dimension (mm) | 2500*1000 *1800 | 3800*1200 *2200 | 4500*1500 *2200 | 5000*1600 *2200 | 6000*2400 *2800 | 7000×2800 ×2750 | 7500×2800 filling |
Detail pictures
