Home > Products > 3&5 Gallon Filling Line > 20L Barreled Water Filling Machine
20L Barreled Water Filling Machine
- shanghai pot
- T/T Credit Card
You May Like
Product Details
| Condition | New | Place of Origin | Jiangsu, China | |
| Brand Name | huanyu | Model Number | QGF-600 | |
| Voltage | 380V50HZ | Power(W) | 2KW | |
| Weight | 2000kg | Processing Types | water | |
| Certification | CE | Warranty | One Year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1.20L barreled water filling machine2.advanced PLC control
3.sus304
4.capacity:1000-1200b/h
5.CE
20L barreled water filling machine
Introuduction of Production
This filling line specially produces 3-5 gallons barreled drinking water,model:100,150,240,300,450,600,900 and 1200. It intergrates bottles washer, fiiller and sealer into one unit. In order to achieve the purpose of washing and sterilizing. The washer adopts multi-way spraying with washing and sterilizing liquid, and the disinfecant can be used circulary. The sealer is automatic .This line equips with water spraying device to ensure those caps are aseptic and healthy, also this line can automatically carry out barrel feeding,washing ,sterilizing ,filling, capping, counting and products discharging, it is a new kind of barreled water auto-producing line,which inergrates mechanism, electricity and pneumatics technologies together.
Main Technical Parameters
| Model | QGF-100 | QGF-240 | QGF-300 | QGF-450 | QGF-600 | QGF-900 | QGF-1200 |
| Filling head | 1 | 2 | 3 | 4 | 8 | 8 | 8 |
| Volume | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 |
| barrel size | 270*490 | 270*490 | 270*490 | 270*490 | 270*490 | 270*490 | 270*490 |
| capacity | 60-100 | 100-240 | 250-300 | 400 | 800 | 800 | 800 |
| gas pressure | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.6 | 0.6 | 0.6 |
| gas consumption | 0.37 | 0.37 | 0.6 | 0.8 | 1 | 1.5 | 1.8 |
| Motor power | 1.38 | 1.75 | 3.8 | 3.8 | 7.5 | 9.75 | 13.5 |
| Rated Voltage | 380V50HZ | 380V50HZ | 380V50HZ | 380V50HZ | 380V50HZ | 380V50HZ | 380V50HZ |
| Weight | 680 | 800 | 1500 | 2100 | 3000 | 3500 | 4500 |
ZhangJiaGang Huanyu Beverage Machinery Co.,Ltd is a professional Manufacturer of Beverage Filling Machine in China. In addition to 5 gallon filling machine, we also produce:Small bottle water filling machine,Juice/Tea drink filling machine,Carbonated drinks/Beer Filling machine,Pop can Filling machine,water treatment equipment, blow molding machine, Bottle Unscrambler ,shrink labeling/packing machine and so on.
More detailed information .Please feel free to contact us.
Name | Derek Liang |
Mobile phone | +86-15962348757 |
Office Tel | +86-0512-58536922 |
Skype | derekmachinery |
522756388 |
