Home > Products > 3&5 Gallon Filling Line > 5 Gallon Barrel Pure Water Filling Machine(QGF-300)
5 Gallon Barrel Pure Water Filling Machine(QGF-300)
- shanghai port
- T/T
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | HY | |
| Model Number | QGF | Weight | 800-5000kg |
Product Description
Specifications
5 gallon barrel filling machine1.With CE certificate
2.Long service life
3.Low maintenace
4.Meet GMP require..
QGF series barrel production line is specially used for 3&5 Gallon barrel drinking water. This machine integrates washing,filling,capping into one unit. It is the good ideal for produce the mineral water,distilled water,pure water equipments. Whole machine are adopt the high quality stainless steel, It's erosion proof ability is strong, easy to washing. Mostly electric components are adopt SIEMENS,OMRON etc famous company. Electric component adopt import Air TAC famous brand product. The machine is advanced in construction,occupying small area,steady in performance,high in produce efficiency, high in automatization degree.easy in operation,which integrates machinery, electricity and pneumatics technologies together into one unit full automatic barreling machine.
TYPE | QGF-100 | QGF-240 | QGF-300 | QGF-600 | QGF-900 | QGF-1200 |
Filling heads | 1 | 2 | 3 | 8 | 8 | 4 |
Barrel Size (mm) | Φ276×490 | Φ276×490 | Φ276×490 | Φ276×490 | Φ276×490 | Φ276×490 |
Capacity (b/h) | 60-100 | 100-240 | 250-300 | 800 | 800 | 800 |
Gas Pressure | 0.4-0.6Mpa | |||||
Gas Consumption | 0.37 | 0.37 | 0.6 | 1 | 1.5 | 1.8 |
Power (KW) | 1.38 | 1.75 | 3.8 | 7.5 | 9.75 | 13.5 |
Voltage | 380V/50HZ | |||||
Outline Size (mm) | 3100×650×1550 | 3190×650×1550 | 3100×900×1650 | 3100×900×1650 | 3550×1100×1800 | 3800×1100×1800 |
Weight (kg) | 680 | 800 | 1500 | 3000 | 3500 | 4500 |
| Barrel Capability | 18.9 L | |||||
