5 Gallon Heat Shrink Machine for Cap
- Shanghai
- T/T Credit Card
You May Like
-
QGF Series Barrel Package Production Line
-
pull out cap machine for 5 gallon barrel
-
5 gallon barrel pure water filling production line (QGF series)
-
Full automatic barrel water filling machine (QGF series)
-
QGF-300 Series 5 Gallon Barrel Water Filling Machine
-
5 Gallon /3 gallon washer, filler and capper monoblock
Product Details
| Place of Origin | Jiangsu, China | Brand Name | HUANYU | |
| Model Number | QGF | Processing Types | Water |
Product Description
Specifications
5 Gallon Heat Shrink Machine for Cap1.With CE certificate
2.Long service life
3.Low maintenace
4.Meet GMP require..
Pull out cap machine for 5 gallon barrel
This heat-shrinking machine has two types of heat-electricity and steam.
Heat-electricity type shrinking machine generate heat by heating pipe. There is a air blower in the top of shrinking tunnel. Shrinkage is finished when bottle mouth enter the shrinking tunnel.
Steam type shrinking machine generate heat by steam generator, shrinkage is finished when bottle mouth enter the steam shrinking tunnel.
Power: 3kw
Steam generator size: 450*500*1400mm
Shrink tunnel: 400*250*1400mm
Voltage: Three-phase 380V
.
5 Gallon Filling Machine
QGF series barrel production line is specially used for 3&5 Gallon barrel drinking water.
TYPE | QGF-100 | QGF-240 | QGF-300 | QGF-600 | QGF-900 | QGF-1200 |
Filling heads | 1 | 2 | 3 | 8 | 8 | 4 |
Barrel Size (mm) | Φ276×490 | Φ276×490 | Φ276×490 | Φ276×490 | Φ276×490 | Φ276×490 |
Capacity (b/h) | 60-100 | 100-240 | 250-300 | 800 | 800 | 800 |
Gas Pressure | 0.4-0.6Mpa | |||||
Gas Consumption | 0.37 | 0.37 | 0.6 | 1 | 1.5 | 1.8 |
Power (KW) | 1.38 | 1.75 | 3.8 | 7.5 | 9.75 | 13.5 |
Voltage | 380V/50HZ | |||||
Outline Size (mm) | 3100×650×1550 | 3190×650×1550 | 3100×900×1650 | 3100×900×1650 | 3550×1100×1800 | 3800×1100×1800 |
Weight (kg) | 680 | 800 | 1500 | 3000 | 3500 | 4500 |
| Barrel Capability | 18.9 L | |||||
