Home > Products > waterproof Constant voltage led driver > electrical 110v ac to 36v dc 250w led transformer

electrical 110v ac to 36v dc 250w led transformer

FOB Price

US$ 10 - 24 / Piece

1 Piece(Min. Order)

Port xiamen
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Fujian, China	Brand Name	SMARTS
Model Number	SMT-036-250VW	Output Power	Other, 250W
Output Type	Single	Input Voltage	Other, 90~135V/ 170-265V
Output Voltage	36V	Output Frequency	47-63Hz
Output Current	6.94A

Product Description

electrical 110v ac to 36v dc 250w led transformer

Product Description

SPECIFICAION
MODEL		SMT-012-250VW	SMT-024-250VW	SMT-036-250VW
OUTPUT	DC VOLTAGE	DC12V	DC24V	DC36V
	RATED CURRENT	20.83A	10.42A	6.94A
	CURRENT RANGE	0-20.83A	0-10.42A	0-6.94A
	RATED POWER	250 W	250W	250W
	RIPPLE&NOISE(max)	150mV	150mV	150mV
	SETUP RISE TIME	80ms/120VAC,220VAC
	HOLD UP TIME(Typ.)	60ms/120VAC,220VAC
INPUT	VOLTAGE RANGE	90~135VAC/170~265VAC
	FREQUENCY RANGE	50~60Hz
	POWER FACTOR(Typ.)	PF0.6-0.8/120VAC,220VAC
	EFFICIENCY(Typ.)	>84%
	AC CURRENT(Typ.)	1.85A/120VAC,220VAC
	INRUSH CURRENT (Typ.)	COLD START 50A/120VAC,220VAC
PROTECTION	Short circuit	Protection type:recovers automatically after condition is removed
	Overload	overload protected@145-160% above peak rating
	Over temperature	Protection type:Shut down o/p voltage,re-power on to removed
ENVIRONMENT	WORKING TEMP.	-40~+50℃ (Refer to output load derating curve)
	WORKING HUMIDITY	20~99% RH non-condensing(Waterproof)
	STORAGE TEMP.,HUMIDITY	-40~+80℃,10~99%RH
SAFETY&EMC	SAFETY STANDARDS	UL/cUL,CE Mark(LVD),IP67
	WITHSTAND VOLTAGE	I/P-O/P:1.5KVAC IP-GND:1.5KVAC
	EMC Test Standards	EN55015:2006;EN61547:1995+2000;EN61000-3-2:2006
		EN61000-3-3:1995+A2:2005;EN61346-1:2001;EN61347-2-13:2006

Features:

IP67 design for indoor or outdoor installations
Protections:Short circuit/Overload/Over temperature
Cooling by free air convection
100% full load burn-in test
Suitable for LED lighting
Products through UL,CE,RoHS Certification
2 years warranty

Note:

All parameters NOT specially mentoned are measured at 120~220VAC input,rated load and 25℃ of ambient temperature.
Ripple&noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf&10uf parallel capacitor.
Tolerance:includes set up tolerance,line regulation and load regulation.

Packaging & Shipping

N.W./pcs	G.W/ctn	Qty/ctn	Carton Size(mm)
electrical 110v ac to 36v dc 250w led transformer
2540g/pcs	12kg/ctn	5pcs	475298185mm

MOQ: 1 pcs
Payment: T/T, Western Union, Paypal, Trade Assurance.
Delivery: 7 working days for sample order,12 working days for 500pcs.
FOB , EXW and CIF all are available.
Shipping freight are quoted under your requests.
Loading port: Xiamen
Discounts are offered based on large quantities.
Price: Get quote

Junction Box

We can supply you ETL approved Junction boxes for all kinds of the LED drivers.
