ac to dc ul 80w led downlight dimmable power supply

Features:

• Constant current design with high accuracy.
• International wide input voltage.
• Wattage: 15w-200w
• 8Hrs and 100% full load burn-in test.
• High reliability designing solution
• Cooling by free air convection
• Suitable for LED lighting and moving sign applications
• High efficiency,save energy ,protected environment
• High stability and low ripple, increase light efficiency and decrease light attenuation
• Meet to safety standard and EMC
• Assure LED stability long lift and light efficiency by constant current
• Passed high ,low temperature testing.
• Integrity protection,over loading, over voltage over current

Specifications:

• model: SMT-067-1020CD
• input:100-265vAC / 47-63HZ
• output: 35-67v @1020mA  80watt
• dimming type: 0-10v/PWM dimmable
• warking mode: constant current

• Efficiency > 88%

• PFC> 0.92
• cover material: aluminium housing
• waterproof rate: IP67
• unit weight: 1100g/pcs
• product size: 200*68*45 mm
• box size:324*298*176mm
• pack qty: 10pcs/ctn
• gross weight: 13.2kg/ctn
• wire requirements:18AWG*20CM
• CE,UL, ROHS approval
• 3 years warranty
• (We promise to replace new ones to you if there is any defective happen during the warranty period)

Environment:

• Working Temperature : -40 ~ +50°C
• Working Humidity : 20 ~ 95% RH non-condensing
• Storage Temp. , Humidity : -40 ~ +80°C , 10 ~ 95% RH
• TEMP. Coefficient : ±0.03%/°C (0 ~ 50°C)
• Vibration : 10 ~ 500Hz, 5G 15min./1cycle, period for 72min. each along X, Y, Z axes

Safety:

• Safety Standards :   EN61347-1 EN61347-2-13. IP40
• Withstand Voltage :   I/P-O/P:3.75KVAC I/P-FG:1.88KVAC O/P-FG:0.5KVAC
• Isolation Resistance :  I/P-O/P I/P-FG O/P-FG:100MΩ/500VDC/25℃/70%RH
• EMC Emission : Compliance to EN55015,EN61000-3-2 (>50%Load)
• EMC Immunity : Compliance to EN61000-4-2,3,4,5,6,8,11,EN61547,A light industry level

Product parameters:

Smarts Electronics, the led driver manufacturer located in Quanzhou,has 6 years trade experience in Alibaba.

We have 7 kinds of led drivers or led power supply:

1.Constant Voltage LED Driver;

2.Constant Current LED Driver;

3.Triac CC&CV Dimmable LED Driver

4.0-10v  CC&CV Dimmable LED Driver

5.DALI CC&CV Dimmable LED Driver

6.Power Adapter

7.Switching Power Supply

What kind of LED Driver/Power Supply We do??

We specialized in constant voltage & current LED drivers, 010v/triac/DALI dimmable led drivers, enclosure power suppliers, power adapters.

Triac CC&CV Dimmable Series	0-10V CC&CV Dimmable Series	DALI CC&CV Dimmable Series
Wall-mount Power Adapter	HOME	Desktop Power Adapter
Constant Voltage Series	Enclosue Power Supply	Constant Current Series

What Service we can supply??

1. All inquiries will be replied within 24 hours


2.  Professional manufacturer,welcom to visit our website


3. OEM/ODM avaliable:
   A.Print logo on our product;
   B. Customized specification;
4. After Sales-Service:
   A. All products will have 100% burn-in test and strictly quality test before shipping;
   B. Fast Delivery: 3-7days for samples, 15-20 days for bulk production;
5. High efficiency,long life span,reasonable&competetative price,fast lead time;
6. We have our engineer team, if you have any question about your LED applications, let us know freely.

***Any questions,Just feel free to click "send" to contact with me.^-^***
