Home > Products > waterproof Constant voltage led driver > CE UL listed 12v 10watt led waterproof power supply module
CE UL listed 12v 10watt led waterproof power supply module
- xiamen
- Credit Card
You May Like
-
waterproof ac dc 24v 6w power supply with CE UL ROHS approval
-
12v 1a switching power supply for led strip with 2 years warranty
-
24v 2.5a 60w constant voltage slim led driver with CE UL
-
CE UL listed 12 volt 60w led driver slim waterproof led power supply
-
ul1310 100-277v ac 12v/24v dc 100 watt led driver
-
24vdc power supply 200w ip67 waterproof isolation transformer
Product Details
Place of Origin | Fujian, China | Brand Name | SMARTS | |
Model Number | SMT-012-120VW | Output Power | Other, 120W | |
Output Type | Single | Input Voltage | Other, 100-265Vac | |
Output Voltage | 12VDC | Output Frequency | 47-63Hz | |
Output Current | 10a |
Product Description
CE UL listed 12v 10watt led waterproof power supply module
SPECIFICAION | |||||
MODEL | SMT-012-120VW | SMT-024-120VW | |||
OUTPUT | DC VOLTAGE | 12V | 24V | ||
RATED CURRENT | 10.0A | 5.0A | |||
CURRENT RANGE | 0~10.0A | 0~5.0A | |||
RATED POWER | 120W | 120W | |||
RIPPLE&NOISE(max) | 150mV | 150mV | |||
VOLTAGE TOLERANCE | ±0.5V | ±0.5V | |||
SETUP RISE TIME | 80ms/110V,220VAC | ||||
HOLD UP TIME(Typ.) | 60ms/110V,220VAC | ||||
INPUT | VOLTAGE RANGE | 100~265VAC | |||
FREQUENCY RANGE | 50~60Hz | ||||
POWER FACTOR(Typ.) | |||||
EFFICIENCY(Typ.) | >83% | ||||
AC CURRENT(Typ.) | 0.92A/110VAC, 0.86A/220VAC | ||||
INRUSH CURRENT (Typ.) | COLD START 50A/110VAC, 220VAC | ||||
PROTECTION | Short circuit | Protection type:recovers automatically after condition is removed | |||
Overload | overload protected@145-160% above peak rating | ||||
Over temperature | Protection type:Shut down o/p voltage,re-power on to removed | ||||
ENVIRONMENT | WORKING TEMP. | -30~+50℃ (Refer to output load derating curve) | |||
WORKING HUMIDITY | 20~99% RH non-condensing(Waterproof) | ||||
STORAGE TEMP.,HUMIDITY | -40~+80℃,10~99%RH | ||||
SAFETY&EMC | SAFETY STANDARDS | CE UL Mark(LVD),IP67 | |||
WITHSTAND VOLTAGE | I/P-O/P:1.5KVAC IP-GND:1.5KVAC | ||||
EMC Test Standards | EN55015:2006;EN61547:1995+2000;EN61000-3-2:2006 | ||||
EN61000-3-3:1995+A2:2005;EN61346-1:2001;EN61347-2-13:2006 | |||||
NOTE | 1.All parameters NOT specially mentoned are measured at 110VAC,220VAC input, rated load and 25℃ of ambient temperature.
2.Ripple&noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf&10uf parallel capacitor.
3.Tolerance:includes set up tolerance,line regulation and load regulation. |
Mechanical Specification
- Cable Model of input : VDE H03VV-F 3G0.75mm2
- Cable Model of output: VDE H03VV-F 2*0.75mm2
