Full-auto BGA Repair Machine Shuttle Star RW-E6250 Pick and Place for Iphone Motherboard

         Full-auto BGA repair machine Shuttle Star RW-E6250 pick and place for iphone motherboard

Product Application

 Laptop, smart phone, ps4,ps3,XBOX,routers，desktop,iphone

Main Features

1)Hot air head and mounting head are designed 2 in 1, and have both the auto soldering and mounting function;

2)Color optical system with functions of split vision, zoom - in and micro-
adjustment,equipped with aberration detection device; with auto focus and software
operation function,22X optical zoom; able to rework BGA sized up to 70mm×70mm;

3)Touch screen interface, PLC control; able to display temperature curves and five detecting curves at the same time;

4)Color LCD monitor;

5)Built-in vacuum pump; 360° rotation in Φ angle; mounting nozzle is micro-adjustable;

6) 6 segments of temperature up (down) and 6 segments constant temperature control, 200
groups of temperature curve are stored; Curve analysis can be carried out on the touch
screen and has the communication function as computers ,with software attached;

7) Able to arrive at three independent temperature zones,temperature and time can be
displayed digitally on the touch screen;able to rework CGA;

8)The supports rack can be adjusted to restrain the local sinkage of the BGA soldering area;

9)Suction nozzle can identify material and mounting height automatically, and can control the
air pressure within a small range;

10)Both upper and lower hot-air heating head are movable on the IR preheating area to fit for
reworking BGA in different positions on PCB;

11) Equipped with different alloy hot air nozzles, easy to replace and able to locate in any angle.

12)Driven by the servo motor,the integrative hot air head can store 20 groups of different BGA
heating points and register marks.

Machine Parts

Name: Lower mix heater

Original: China

Bottom heating is mixed heation system with hot gas and IR,

In vacuum pump,360' rotation in any angle by motor.

Machine parts

Name: Bottom heating zone
Original: China
Large IR area heater from the bottom will heat the PCB evenly to avoid deformation.

Machine Parts

Name: Nitregen&Air port
Original: China
leave nitrogen protection, saving nitrogen to save cost .

Machine parts

Name: Flexile jigs
Original: China
Easy to fix the PCB with different components

                                                                 Automatic soldering and mounting

                                                                  Flexible and PC irregular clamps

                              Equipped with different nozzles for your choose
