Alcohol injection integrated unit Skid for gas field
- Any port in China
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
mounted chemical injection skid for oil wells
-
Chemical Injection Packge/ Injection Skid
-
chemical injection device for oil & gas project
-
Methyl Alcohol Injection Skid Unit for Oilfield Well Operation
-
Chemical Injection System Skid mounted for Oil and Gas Well Operation
-
ASME oil and gas equipment chemical injection skids
Product Details
| Place of Origin | Shaanxi, China | Brand Name | SHBF | |
| Model Number | SHBF-025 | Theory | Centrifugal Pump | |
| Structure | Multistage Pump | Standard or Nonstandard | Nonstandard | |
| Fuel | Gasoline | Pressure | Low Pressure | |
| Application | Other |
Product Description
Alcohol injection Skid For Oilfield
Equipment function
Alcohol injection Integrated device, is mainly composed of corrosion inhibitor, defoaming agent tank, dosing pump, on-site alcohol injection single pump, wellhead injection alcohol double pump, corrosion inhibitor injection pump and filter, valves, etc. Mainly includes the wellsite to alcohol, on-site alcohol injection and injection defoaming agent, corrosion inhibitor, etc.
Technical parameter
No. | Technical requirement |
| |||||||
1 | Medium | Methyl Alcohol | |||||||
2 | Medium inlet temperature |
| |||||||
| Minimum | -3℃ | Normal | 20℃ | Maximum | 40℃ | |||
3 | Inlet pressure |
| |||||||
| Minimum | 0.1MPa | Normal | 0.3MPa | Maximum | 0.5 MPa | |||
4 | Environment temperature |
| |||||||
| Minimum | -23℃ | Normal | 10.4℃ | Maximum | 41.1℃ | |||
5 | Density in inlet condition | 791.4Kg/m3 | Viscosity in inlet condition | 0.5852 Mpa | |||||
6 | Vapour pressure inlet condition | 0.031MPa | The effective net positive suction hea | 10-50m | |||||
7 | The rated capacity | 100L/h Double end | The rated exhaust pressure | 23MPa(G) | Flow regulation | Manual operation | |||
Please send me your requirment, then we could offer you the suitable style and competitive price.
