BZT-300 mechnical trailer water well drilling rig

FOB Price

US$ 1 - 100,000 / Set

1 Set(Min. Order)

Port Tianjin China
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Rotary Drilling Rig
Power Type	Diesel	Place of Origin	Shandong, China
Brand Name	BINZUAN	Model Number	BZT-300
Usage	Water Well	Voltage	380V
Power(W)	80Hp	Dimension(LWH)	1120024803670mm
Weight	13500kg	Certification	Iso9001:2008
Warranty	at least 1 year	After-sales Service Provided	Overseas service center available

Product Description

Specifications

Drilling depth :300m
Drilling diameter : 190-800mm
Mud pump : BW850
Drill pipe: 86*10*5500mm
Good quality and competitive

1. BZT-300 water well drilling rig is a turntable type rotary drilling rig which is mainly applied to hydro-geological exploration exploration and other projects with holes.

2. It can drill in the Quaternary, fine particle formation and the general soft rock layer

3. The base machine, mud pump and motor engine are installed in a specially designed semi-trailer chassis which can be easily and quickly moved

4. The rig is driven by mechanical transmission, simple operation, economical transportation and reliable to use, easy maintenance, etc.

5. Power force is from the diesel engine or motor engine which can be easily used outdoors

6. The rotary table can provide six different speeds which can meet the requirement of different stratigraphy drilling and it will be beneficial to improve rig efficiency

7. The rig can erect by itself, convenient and reliable

8. The main winch and deputy winch are all using a planetary gear structure which can be operated conveniently and reliably

9. The rig is equipped with generators for the using of lighting, welding machine etc.

Model of drilling rig	BZT-300
Drilling depth	300m
Drilling diameter	200-800mm
Diameter of rotary table thur hole	450mm
Speed of rotary table	44,77,139r/min
Capacity with single rope of winch
Main winch	30KN
Auxiliary winch	20KN
Speed with single rope of winch
Main winch	0.65, 1.16, 2.08m/s
Auxiliary winch	0.46, 0.80, 1.44m/s
Specification of kelly	1081087500mm
Specification of drill pipe	89*10mm
Type of drilling mast	II
Rated load	240KN
Effective height of mast	11.6m
Mud pump	BW850/2A
Diameter of cylinder	150mm
Stroke of piston	180mm
Flow rate	850L/min 600L/min
Pressure	2Mpa 3Mpa
Diesel engine
Engine model	4135Na
Power	80Hp
Speed	1500r/min
Dimension	1120024803670mm
Total weight	13500kg
