Supper durable! 300m(BZC350ZYII) water well drilling rig

FOB Price

USD $1 - $150,000 / Set

1 Set(Min. Order)

Port Any of Chinese port
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Rotary Drilling Rig
Power Type	Diesel	Place of Origin	Shandong, China
Brand Name	BINZUAN	Model Number	BZC350ZYII
Usage	Water Well	Voltage	380V
Power(W)	132000	Dimension(LWH)	1216024903440mm
Weight	19340kg	Certification	ISO9001:2008
Warranty	at least 1 year	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

The truck chassis adopts the 6X4 special crane chassis of brand SINOTRUK;
BW850/2A mud pump;
set up a generator (30kw).

Main features:

1.BZC350ZYII truck mounted drilling rig is designed by our engineers; it adopts truck mounted and is a rotary drilling rig.

2.The truck chassis adopts the 6X4 special crane chassis of brand SINOTRUK, the main transmit, transmission power, gearbox, sets of windlass, mud pump, sewage pump,mast are set up on the chassis.

3.This rig is a rotary drilling rig with directional circulation, which is equipped with BW850/2A mud pump, It adopts the slurry as the washing fluid, it can drill on clay, sand and rock if it is equipped with a good drilling bit.

4.The power of drilling rig comes from the truck engine, the rig setups distribute implement and hydraulic system.

5.We can upset the spare electric engine and clutch implement according to client's requirement, so that the rig can work with diesel engine or electric engine.

6.We can set up a generator (15kw) , so that it is convenient to illuminate or work at night.

7.The adding pressure device is hydraulic, so it has a high efficiency when the rig drill on mud rock and weathering formation through using the adding pressure implement.

8.The master driving of rig is mechanical, the four jacks and mast are hydraulic operated. Distribute box, sewage pump, master driving clutch system are air operated.

9.The appearance of rig is pretty, it has a high efficiency because of having a larger torque of the turntable, it is mainly used for water well, construction, national defense building foundation, geological exploration, geothermic well and other foundation working, it is popular with domestic and foreign clients.

Technical parameter
Drilling depth(M)				300
Drilling diameter(mm)				500
Speed of turntable(r/min)			21.2;36;63.2;100.6;155;20.2(reverse)
Torque of turntable(KN.m)			18;10.6;6;3.8;2.5;18.9(reverse)
Single rope lifting capacity of mian windlass(KN)			30

The capacity of main windlass(KN)			180
Single rope lifting capacity of hydraulic windlass(KN)			40
The capacity of hydraulic windlass(KN)			160
The lifting capacity of hook(KN)			180
Bearing capacity of mast (KN)			180
The height of mast (mm)			11500
Bearing capacity (t)			25
Pipe	Kelly bar(mm)		108×108×7500
	Assistant pipe (mm)		89×10×5500
Hydraulic pump	Model		CB-HP50/32Z
	Pump delivery (ml/r)		50/32
	Rated speed (r/min)		2000
	Rated pressure(MPa)		20
BW850/2A plunger pump	Diameter of cylinder (mm)		150
	Stroke of piston (mm)		180
	Theory of flow (L / min)		600 850
	Rated pressure (Mpa)		3 2
	Pounding times (min^-1)		58 82
	Diameter of suction tube (mm)		127
	Diameter of drain pipe (mm)		64
	Input speed (r / min)		470
	Input power (kw)		40
	Overall dimensions (mm)		200010301400
	Weight (t)		1.5
Truck chassis	Model		TAZ5191TZJ
	Drive form		6×4
	Engine	Model	TBD226B-6Ⅱ(Europe II emission standard)
		Rated power(KW)	132
		Speed (r/min)	2300
	Size (LWH)(mm)		11110×2490×2500
Electric generator	Model		MF
	Rated power (kw)		15
	Rated voltage(v)		400
	Rated current(A)		27
	Speed (r/min)		1500
	Frequency(Hz)		50
	Protection level		IP21
	Insulation Class		H
The best working gear (or speed)			5^thgear(1000-1400r/min)
The highest speed(Km/h)			75
Weight (kg)			19340
Transport size(LWH)(mm)			1216024903440
Working size(LWH)(mm)			11110249013110
