BZCT300SZ tralier mounted drilling rig

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Port tianjingang
Payment TermsT/T L/C

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China		Brand Name	binzuan
Model Number	BZCT300SZ		After-sales Service Provided	Engineers available to service machinery overseas

Product Description

DESCRIPTION:

Main features:

1BZCT300SZ tralier mounted drilling rig is designed by our engineers; it is adopt trailer mounted and is a rotary drilling rig.

2This rig is a rotary drilling rig with directional circulation, which is equipped with BW850/2A mud pump. It adopts the slurry as the washing fluid, it can drill on clay, sand and rock if it is equipped with a good drilling bit.

3The power of drilling rig comes from the diesel engine; the rig sets up distribute implement and hydraulic system.

4The adding pressure implement is hydraulic, so it has a high efficiency when the rig drill on mud rock and weathering formation through using the adding pressure implement.

5The master driving of rig is mechanical, the four jacks and mast are hydraulic operated. Distribute box, sewage pump, master driving clutch system are air operated.

6The appearance of rig is pretty. It has a high efficiency because of having a larger torque of the turntable, it is mainly used for water well, construction, national defense building foundation, geological exploration, geothermic well and other foundation working. It is popular with domestic and foreign clients.

Technical parameter
Drilling depth(M)				300
Drilling diameter(mm)				500
Speed of turntable(r/min)			50;75;114(reverse)
Torque of turntable(KN.m)			13.2;8.8;5.8(reverse)
Single rope lifting capacity of main windlass(KN)			30
The capacity of main windlass(KN)			180
Single rope lifting capacity of assist windlass(KN)			40
The capacity of assist windlass(KN)			160
The lifting capacity of hook(KN)			180
Bearing capacity of mast (KN)			180
The height of mast (mm)			11900
Bearing capacity (t)			25
Pipe	Kelly (mm)		108×108×7500
	Assistant pipe (mm)		89×10×5500
Hydraulic pump	Model		C-HP50
	Pump delivery (ml/r)		50
	Rated speed (r/min)		2000
	Rated pressure(MPa)		20
BW850/2A plunger pump	Diameter of cylinder (mm)		150
	Stroke of piston (mm)		180
	Theory of flow (L / min)		600 850
	Rated pressure (Mpa)		3 2
	Pounding times (min^-1)		58 82
	Diameter of suction tube (mm)		127
	Diameter of drain pipe (mm)		64
	Input speed (r / min)		470
	Input power (kw)		40
	Overall dimensions (mm)		200010301400
	Weight (t)		1.5
Diesel engine

	Engine	Model	NC6110
		Rated power(KW)	115
		Speed (r/min)	1100











Weight (kg)			15340
Transport size(LWH)(mm)			1250024803500
Working size(LWH)(mm)			9677248013600
