CCAM Wire Drawing Machine
- Shanghai
- T/T Credit Card
You May Like
Product Details
| Condition | New | Inlet Diameter | 0.6-1.2mm | |
| Outlet Diameter | 0.1-0.3mm | Place of Origin | Jiangsu, China | |
| Brand Name | Jiacheng | Model Number | JCJX-24DL | |
| Voltage | 380/415/440/220 | Power(W) | 10000 | |
| Dimension(L*W*H) | 2.0m 1.6m 1.9m | Weight | 2000kg | |
| Certification | CE,ISO9001:2008,TUV | Warranty | 12 Months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
CCAM wire drawing machine is used for drawing fine wire from 0.6-1.2mm to 0.10-0.30mm.
Advantage:
1). Double inverter can keep the outlet wire precisely tension and the slip ratio of wire will be reduced to the minimum.
2). This CCA wire drawing machine’s body and other key components and parts are produced by our own factory, quality is reliable
3).High tension durably flat belt gain convenient replacement and low noise in operating.
4).This CCA wire drawing machine use elcctronic components of international well-known manufactures,such as:Japan NSK bearing,Switzerland SKF belt,France Schneider electric and Shenzhen Inovance inverter.
5).we have gotten ISO 9001:2008,CE and BV certificate.
After-sell service
Pre-sale training:In order to guarantee the customers are able fully to operate the machine, if the customer need, we can help customer training, includes:
(1) Correct operating mode
(2) Correct maintenance way
(3) Remove simple problem
Guarantees
Since the shipment date, 12 month for mechanical part, and 6 month for electrical part.
